#include <arch/avr32.h>
#include <stdlib.h>
#include <string.h>
#include <dev/gpio.h>
#include <avr32/io.h>

Include dependency graph for gpio_nutos.c:

Defines
#define	PERIPHERALS_MASK (GPIO_CFG_PERIPHERAL0\|GPIO_CFG_PERIPHERAL1\|GPIO_CFG_PERIPHERAL2\|GPIO_CFG_PERIPHERAL3)
Functions
int	GpioPinGet (int bank, int bit)
	Get pin level.
void	GpioPinSetLow (int bank, int bit)
	Set pin level to low.
void	GpioPinSetHigh (int bank, int bit)
	Set pin level to high.
void	GpioPinSet (int bank, int bit, int value)
	Set pin level.
unsigned int	GpioPortGet (int bank)
	Get all pin levels of a specified bank/port.
void	GpioPortSetLow (int bank, unsigned int mask)
	Set multiple pin levels of a bank/port to low.
void	GpioPortSetHigh (int bank, unsigned int mask)
	Set multiple pin levels of a bank/port to high.
void	GpioPortSet (int bank, unsigned int value)
	Set all pin levels of a bank/port.
uint32_t	GpioPinConfigGet (int bank, int bit)
	Get pin configuration.
int	GpioPortConfigSet (int bank, unsigned int mask, uint32_t flags)
	Set port wide pin configuration.
int	GpioPinConfigSet (int bank, int bit, uint32_t flags)
	Set pin configuration.
int	GpioRegisterIrqHandler (GPIO_SIGNAL sig, int bit, void(handler)(void ), void arg)
	Register a GPIO pin interrupt handler.
int	GpioIrqEnable (GPIO_SIGNAL *sig, int bit)
	Enable a specified GPIO interrupt.
int	GpioIrqDisable (GPIO_SIGNAL *sig, int bit)
	Disable a specified GPIO interrupt.

Define Documentation

#define PERIPHERALS_MASK (GPIO_CFG_PERIPHERAL0|GPIO_CFG_PERIPHERAL1|GPIO_CFG_PERIPHERAL2|GPIO_CFG_PERIPHERAL3)

Referenced by GpioPortConfigSet().

Function Documentation

int GpioPinGet	(	int	bank,
		int	bit
	)

Get pin level.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.

Returns:: 1 if the pin level is high. 0 is returned if the pin level is low or if the pin is undefined.

Definition at line 153 of file gpio_nutos.c.

Referenced by sys_key().

void GpioPinSetLow	(	int	bank,
		int	bit
	)

Set pin level to low.

Trying to set undefined pins is silently ignored.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.

Definition at line 169 of file gpio_nutos.c.

Referenced by GpioPinSet(), GpioSpiBus0Select(), init_dio(), and ProcessRequests().

void GpioPinSetHigh	(	int	bank,
		int	bit
	)

Set pin level to high.

Trying to set undefined pins is silently ignored.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.

Definition at line 185 of file gpio_nutos.c.

Referenced by GpioPinSet(), InitLED(), and ProcessRequests().

void GpioPinSet	(	int	bank,
		int	bit,
		int	value
	)

Set pin level.

Trying to set undefined pins is silently ignored.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.
value	Level, 0 for low or any other value for high.

Definition at line 202 of file gpio_nutos.c.

Referenced by NutSetLed().

unsigned int GpioPortGet ( int bank )

Get all pin levels of a specified bank/port.

Parameters:

bank	GPIO bank/port number.

Returns:: Pin levels. 0 is returned for unknown banks and pins.

Definition at line 221 of file gpio_nutos.c.

Referenced by GpioPortSetHigh(), and GpioPortSetLow().

void GpioPortSetLow	(	int	bank,
		unsigned int	mask
	)

Set multiple pin levels of a bank/port to low.

Parameters:

bank	GPIO bank/port number.
mask	Pin levels are set to low, if the corresponding bit in this mask is 1.

Returns:: Levels.

Definition at line 238 of file gpio_nutos.c.

Referenced by GpioPortSet().

void GpioPortSetHigh	(	int	bank,
		unsigned int	mask
	)

Set multiple pin levels of a bank/port to high.

Trying to set undefined ports is silently ignored.

Parameters:

bank	GPIO bank/port number.
mask	Pin levels are set to high, if the corresponding bit in this mask is 1.

Definition at line 255 of file gpio_nutos.c.

Referenced by GpioPortSet().

void GpioPortSet	(	int	bank,
		unsigned int	value
	)

Set all pin levels of a bank/port.

This routine can be used to simultaneously set all pins of a specific port. However, in some implementations the high bit values will be set before the low bit values. If this is a problem, you should use GpioPortSetHigh() and GpioPortSetLow().

Parameters:

bank	GPIO bank/port number.
value	Pin levels are set to high, if the corresponding bit in this mask is 1. All other pin levels are set to low.

Definition at line 276 of file gpio_nutos.c.

Referenced by GpioPortSetHigh(), and GpioPortSetLow().

uint32_t GpioPinConfigGet	(	int	bank,
		int	bit
	)

Get pin configuration.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.

Returns:: Attribute flags of the pin.

Definition at line 292 of file gpio_nutos.c.

References _BV, GPIO_CFG_DEBOUNCE, GPIO_CFG_DISABLED, GPIO_CFG_OUTPUT, GPIO_CFG_PERIPHERAL0, GPIO_CFG_PERIPHERAL1, GPIO_CFG_PERIPHERAL2, GPIO_CFG_PERIPHERAL3, and GPIO_CFG_PULLUP.

Referenced by GpioPinConfigSet().

int GpioPortConfigSet	(	int	bank,
		unsigned int	mask,
		uint32_t	flags
	)

Set port wide pin configuration.

Note:: This function does not check for undefined ports and pins or invalid attributes. If this is required, use GpioPinConfigSet().

Parameters:

bank	GPIO bank/port number.
mask	The given attributes are set for a specific pin, if the corresponding bit in this mask is 1.
flags	Attribute flags to set.

Returns:: Always 0.

Definition at line 349 of file gpio_nutos.c.

References GPIO_CFG_DEBOUNCE, GPIO_CFG_DISABLED, GPIO_CFG_OUTPUT, GPIO_CFG_PULLUP, and PERIPHERALS_MASK.

Referenced by GpioPinConfigSet().

int GpioPinConfigSet	(	int	bank,
		int	bit,
		uint32_t	flags
	)

Set pin configuration.

Applications may also use this function to make sure, that a specific attribute is available for a specific pin.

Note:: GPIO pins are typically initialized to a safe state after power up. This routine is not able to determine the consequences of changing pin configurations. In the worst case you may permanently damage your hardware by bad pin settings.

Parameters:

bank	GPIO bank/port number.
bit	Bit number of the specified bank/port.
flags	Attribute flags.

Returns:: 0 if all attributes had been set, -1 otherwise.

Definition at line 406 of file gpio_nutos.c.

References _BV, GpioPinConfigGet(), and GpioPortConfigSet().

Referenced by GpioSpiBus0Select(), init_dio(), InitKEY(), and InitLED().

Here is the call graph for this function:

int GpioRegisterIrqHandler	(	GPIO_SIGNAL *	sig,
		int	bit,
		void()(void )	handler,
		void *	arg
	)

Register a GPIO pin interrupt handler.

Generating interrupts on GPIO pin changes is not supported on all platforms. In this case dedicated external interrupt pins may be used with NutRegisterIrqHandler().

Interrupts are triggered on rising and falling edges. Level triggering or triggering on specific edges is not supported.

After registering, interrupts are disabled. Calling GpioIrqEnable() is required to activate the interrupt.

The following code fragment registers an interrupt handler which is called on each change of bit 4 of the first GPIO port:

 #include <dev/gpio.h>

 static void PinChange(void *arg)
 {
     ...
 }

 {
     ...
     GpioPinConfigSet(0, 4, GPIO_CFG_PULLUP);
     GpioRegisterIrqHandler(&sig_GPIO, 4, PinChange, NULL);
     GpioIrqEnable(&sig_GPIO, 30);
     ...
 }

Parameters:

sig	Bank/port interrupt to be associated with this handler.
bit	Bit number of the specified bank/port.
handler	This routine will be called by Nut/OS, when the specified pin changes its state.
arg	Argument to be passed to the interrupt handler routine.

Returns:: 0 on success, -1 otherwise.

Definition at line 457 of file gpio_nutos.c.

References GPIO_SIGNAL::ios_handler, GPIO_SIGNAL::ios_sig, GPIO_SIGNAL::ios_vector, GPIO_VECTOR::iov_arg, GPIO_VECTOR::iov_handler, malloc(), memset(), NutIrqEnable(), and NutRegisterIrqHandler().

Here is the call graph for this function:

int GpioIrqEnable	(	GPIO_SIGNAL *	sig,
		int	bit
	)

Enable a specified GPIO interrupt.

A related interrupt handler must have been registered before calling this function. See GpioRegisterIrqHandler().

Parameters:

sig	Interrupt to enable.
bit	Bit number of the specified bank/port.

Returns:: 0 on success, -1 otherwise.

Definition at line 492 of file gpio_nutos.c.

References GPIO_SIGNAL::ios_ctl, and NUT_IRQCTL_ENABLE.

int GpioIrqDisable	(	GPIO_SIGNAL *	sig,
		int	bit
	)

Disable a specified GPIO interrupt.

Parameters:

sig	Interrupt to disable.
bit	Bit number of the specified bank/port.

Returns:: 0 on success, -1 otherwise.

Definition at line 505 of file gpio_nutos.c.

References GPIO_SIGNAL::ios_ctl, and NUT_IRQCTL_DISABLE.
