Data Structures
struct	_BLOCK_USAGE
	Internal block usage cache structure. More...
struct	_BLOCKHEAD
	UFLASH block header. More...
struct	_BLOCKFOOT
	UFLASH block footer. More...
struct	_ENTRYHEAD
struct	_UFLASHENTRY
	File system entry descriptor. More...
struct	_UFLASHVOLUME
	Volume info structure. More...
struct	_UFLASHFIND
	Entry search structure. More...
Defines
#define	UFLASH_MAX_BLOCKS 8192
	Max. number of blocks per file system.
#define	UFLASH_BLOCK_UNITS 4
	Number of units per block.
#define	UFLASH_ENTRIES 128
	Number of file system entries.
#define	UFLASH_USAGE_CACHE 32
	Size of the least used buffer.
#define	UFLASH_MAX_PATH 0
	Maximum lenght of a full absolute path.
#define	UFLASH_BLOCK_INVALID ((blknum_t)-1)
#define	UFLASH_VOLF_FIXED 0x80
Typedefs
typedef uint16_t	blknum_t
typedef uint_fast16_t	blknum_fast_t
typedef struct _BLOCK_USAGE	BLOCK_USAGE
	Internal block usage cache structure.
typedef struct _BLOCKHEAD	BLOCKHEAD
	UFLASH block header.
typedef struct _BLOCKFOOT	BLOCKFOOT
	UFLASH block footer.
typedef struct _ENTRYHEAD	ENTRYHEAD
typedef struct _UFLASHENTRY	UFLASHENTRY
	File system entry descriptor.
typedef struct _UFLASHVOLUME	UFLASHVOLUME
	Volume info structure type.
typedef struct _UFLASHFIND	UFLASHFIND
	Entry search structure.
Functions
int	UFlashAttach (NUTDEVICE dev, NUTSERIALFLASH sfi, NUTSPIBUS *bus)
	Attach an UFLASH file system to a serial flash device.
void	UFlashDetach (NUTDEVICE *dev)
	Detach an UFLASH file system from a serial flash device.
int	UFlashFormat (NUTDEVICE dev, NUTSERIALFLASH sfi, NUTSPIBUS *bus)
	Format an UFLASH volume.
Variables
NUTDEVICE	devUFlash0
	UFLASH0 file system device.
NUTDEVICE	devUFlash1
	UFLASH1 file system device.

Define Documentation

#define UFLASH_MAX_BLOCKS 8192

Max. number of blocks per file system.

Definition at line 101 of file uflashfs.c.

Referenced by UFlashFormat().

#define UFLASH_BLOCK_UNITS 4

Number of units per block.

Definition at line 106 of file uflashfs.c.

Referenced by UFlashFormat().

#define UFLASH_ENTRIES 128

Number of file system entries.

Definition at line 111 of file uflashfs.c.

#define UFLASH_USAGE_CACHE 32

Size of the least used buffer.

Definition at line 116 of file uflashfs.c.

#define UFLASH_MAX_PATH 0

Maximum lenght of a full absolute path.

If not defined, a variable path name length is used. Note, that the total size of the name is still limited, because the block header and the entry header must fit into the first unit of the file system block.

Definition at line 138 of file uflashfs.c.

#define UFLASH_BLOCK_INVALID ((blknum_t)-1)

Definition at line 141 of file uflashfs.c.

#define UFLASH_VOLF_FIXED 0x80

Definition at line 225 of file uflashfs.c.

Typedef Documentation

typedef uint16_t blknum_t

Definition at line 123 of file uflashfs.c.

typedef uint_fast16_t blknum_fast_t

Definition at line 124 of file uflashfs.c.

typedef struct _BLOCK_USAGE BLOCK_USAGE

Internal block usage cache structure.

typedef struct _BLOCKHEAD BLOCKHEAD

UFLASH block header.

Each used block starts with a BLOCKHEAD structure.

typedef struct _BLOCKFOOT BLOCKFOOT

UFLASH block footer.

Each block ends with a BLOCKFOOT structure.

typedef struct _ENTRYHEAD ENTRYHEAD

typedef struct _UFLASHENTRY UFLASHENTRY

File system entry descriptor.

typedef struct _UFLASHVOLUME UFLASHVOLUME

Volume info structure type.

Definition at line 228 of file uflashfs.c.

typedef struct _UFLASHFIND UFLASHFIND

Entry search structure.

Function Documentation

int UFlashAttach	(	NUTDEVICE *	dev,
		NUTSERIALFLASH *	sfi,
		NUTSPIBUS *	bus
	)

Attach an UFLASH file system to a serial flash device.

This function will initialize the hardware and mount the volume.

Parameters:

dev	Specifies the file system device.
sfi	Specifies the serial flash interface.
bus	Specifies the SPI bus driver.

Returns:: 0 on success, -1 on errors.

Definition at line 1842 of file uflashfs.c.

References _NUTSPIBUS::bus_initnode, _NUTSPIBUS::bus_mutex, _NUTDEVICE::dev_icb, _NUTSPINODE::node_bus, NUTASSERT, NutEventPost(), _NUTSERIALFLASH::sf_init, and _NUTSERIALFLASH::sf_node.

Here is the call graph for this function:

void UFlashDetach ( NUTDEVICE * dev )

Detach an UFLASH file system from a serial flash device.

This function will unmount the volume and release all occupied resources.

Parameters:

dev	Specifies the file system device.

Returns:: 0 on success, -1 on errors.

Definition at line 1877 of file uflashfs.c.

References _NUTDEVICE::dev_icb, NUTASSERT, and _NUTSERIALFLASH::sf_exit.

int UFlashFormat	(	NUTDEVICE *	dev,
		NUTSERIALFLASH *	sfi,
		NUTSPIBUS *	bus
	)

Format an UFLASH volume.

Formatting an UFLASH volume is easy: All blocks are simply erased. Therefore, formatting is required only to remove existing contents, which is incompatible with the current format options. The caller must make sure, that the volume is not mounted.

Parameters:

dev	Specifies the file system device.
sfi	Specifies the serial flash interface.
bus	Specifies the SPI bus driver.

Returns:: 0 on success, -1 on errors.

Definition at line 1905 of file uflashfs.c.

References _NUTSPIBUS::bus_initnode, _NUTSPIBUS::bus_mutex, _NUTDEVICE::dev_dcb, _NUTSPINODE::node_bus, NUTASSERT, NutEventPost(), _NUTSERIALFLASH::sf_exit, _NUTSERIALFLASH::sf_init, _NUTSERIALFLASH::sf_node, _NUTSERIALFLASH::sf_rsvbot, _NUTSERIALFLASH::sf_rsvtop, _NUTSERIALFLASH::sf_units, UFLASH_BLOCK_UNITS, and UFLASH_MAX_BLOCKS.

Here is the call graph for this function:

Variable Documentation

NUTDEVICE devUFlash0

Initial value:

 {
    0,
    {'U', 'F', 'L', 'A', 'S', 'H', '0', 0, 0}
    ,
    IFTYP_FS,
    0,
    0,
    NULL,
    NULL,
    UFlashInit,
    UFlashIOCtl,
    UFlashFileRead,
    UFlashFileWrite,

    UFlashFileWrite_P,

    UFlashFileOpen,
    UFlashFileClose,
    UFlashFileSize
}

UFLASH0 file system device.

Definition at line 2039 of file uflashfs.c.

NUTDEVICE devUFlash1

Initial value:

 {
    0,
    {'U', 'F', 'L', 'A', 'S', 'H', '1', 0, 0}
    ,
    IFTYP_FS,
    1,
    0,
    NULL,
    NULL,
    UFlashInit,
    UFlashIOCtl,
    UFlashFileRead,
    UFlashFileWrite,

    UFlashFileWrite_P,

    UFlashFileOpen,
    UFlashFileClose,
    UFlashFileSize
}

UFLASH1 file system device.

Definition at line 2063 of file uflashfs.c.
