SNMP

Simple network management protocol. More...

Collaboration diagram for SNMP:

Data Structures
struct	_viewEntry
struct	_communityEntry
struct	_SNMPVAR
struct	_SNMP_VARLIST
struct	SNMP_PDU
struct	SNMP_SESSION
struct	_SUBTREE
Defines
#define	SNMP_PORT   161
	Standard UDP port for SNMP agents to receive requests messages.
#define	SNMP_TRAP_PORT   162
	Standard UDP port for SNMP managers to receive notificaion messages.
#define	SNMP_MAX_LEN   500
	Default maximum message size.
#define	SNMP_VERSION_1   0
	SNMPv1.
#define	SNMP_VERSION_2C   1
	SNMPv2c.
#define	SNMP_VERSION_3   3
	SNMPv3.
#define	SNMP_MSG_GET   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x0)
#define	SNMP_MSG_GETNEXT   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x1)
#define	SNMP_MSG_RESPONSE   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x2)
#define	SNMP_MSG_SET   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x3)
#define	SNMP_MSG_TRAP   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x4)
#define	SNMP_MSG_GETBULK   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x5)
#define	SNMP_MSG_INFORM   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x6)
#define	SNMP_MSG_TRAP2   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x7)
#define	SNMP_MSG_REPORT   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x8)
#define	SNMP_NOSUCHOBJECT   (ASN_CONTEXT | ASN_PRIMITIVE | 0x0)
#define	SNMP_NOSUCHINSTANCE   (ASN_CONTEXT | ASN_PRIMITIVE | 0x1)
#define	SNMP_ENDOFMIBVIEW   (ASN_CONTEXT | ASN_PRIMITIVE | 0x2)
#define	SNMP_ERR_NOERROR   0
#define	SNMP_ERR_TOOBIG   1
#define	SNMP_ERR_NOSUCHNAME   2
#define	SNMP_ERR_BADVALUE   3
#define	SNMP_ERR_READONLY   4
#define	SNMP_ERR_GENERR   5
#define	SNMP_ERR_NOACCESS   6
#define	SNMP_ERR_WRONGTYPE   7
#define	SNMP_ERR_WRONGLENGTH   8
#define	SNMP_ERR_WRONGENCODING   9
#define	SNMP_ERR_WRONGVALUE   10
#define	SNMP_ERR_NOCREATION   11
#define	SNMP_ERR_INCONSISTENTVALUE   12
#define	SNMP_ERR_RESOURCEUNAVAILABLE   13
#define	SNMP_ERR_COMMITFAILED   14
#define	SNMP_ERR_UNDOFAILED   15
#define	SNMP_ERR_AUTHORIZATIONERROR   16
#define	SNMP_ERR_NOTWRITABLE   17
#define	SNMP_ERR_INCONSISTENTNAME   18
#define	SNMP_TRAP_COLDSTART   0
#define	SNMP_TRAP_WARMSTART   1
#define	SNMP_TRAP_LINKDOWN   2
#define	SNMP_TRAP_LINKUP   3
#define	SNMP_TRAP_AUTHFAIL   4
#define	SNMP_TRAP_EGPNEIGHBORLOSS   5
#define	SNMP_TRAP_ENTERPRISESPECIFIC   6
#define	SNMP_OID_INTERNET   1, 3, 6, 1
#define	SNMP_OID_ENTERPRISES   SNMP_OID_INTERNET, 4, 1
#define	SNMP_OID_MIB2   SNMP_OID_INTERNET, 2, 1
#define	SNMP_OID_SNMPV2   SNMP_OID_INTERNET, 6
#define	SNMP_OID_SNMPMODULES   SNMP_OID_SNMPV2, 3
#define	SNMP_PARSE_ERROR   -1
#define	SNMP_BUILD_ERROR   -2
#define	MAX_SID_LEN   32
	Maximum length of a community name.
#define	MAX_NAME_LEN   128
	Maximum number of sub IDs in an OID.
#define	SNMP_ACT_RESERVE1   0
#define	SNMP_ACT_RESERVE2   1
#define	SNMP_ACT_COMMIT   2
#define	SNMP_ACT_ACTION   3
#define	SNMP_ACT_FREE   4
#define	SNMP_MAX_MSG_SIZE   1472
#define	SNMP_STAT_INPKTS   0
#define	SNMP_STAT_OUTPKTS   1
#define	SNMP_STAT_INBADVERSIONS   2
#define	SNMP_STAT_INBADCOMMUNITYNAMES   3
#define	SNMP_STAT_INBADCOMMUNITYUSES   4
#define	SNMP_STAT_INASNPARSEERRS   5
#define	SNMP_STAT_INTOOBIGS   6
#define	SNMP_STAT_INNOSUCHNAMES   7
#define	SNMP_STAT_INBADVALUES   8
#define	SNMP_STAT_INREADONLYS   9
#define	SNMP_STAT_INGENERRS   10
#define	SNMP_STAT_INTOTALREQVARS   11
#define	SNMP_STAT_INTOTALSETVARS   12
#define	SNMP_STAT_INGETREQUESTS   13
#define	SNMP_STAT_INGETNEXTS   14
#define	SNMP_STAT_INSETREQUESTS   15
#define	SNMP_STAT_INGETRESPONSES   16
#define	SNMP_STAT_INTRAPS   17
#define	SNMP_STAT_OUTTOOBIGS   18
#define	SNMP_STAT_OUTNOSUCHNAMES   19
#define	SNMP_STAT_OUTBADVALUES   20
#define	SNMP_STAT_OUTGENERRS   21
#define	SNMP_STAT_OUTGETREQUESTS   22
#define	SNMP_STAT_OUTGETNEXTS   23
#define	SNMP_STAT_OUTSETREQUESTS   24
#define	SNMP_STAT_OUTGETRESPONSES   25
#define	SNMP_STAT_OUTTRAPS   26
#define	SNMP_STAT_ENABLEAUTHENTRAPS   27
#define	SNMP_STAT_MAX   28
#define	SNMP_VIEW_INCLUDED   1
#define	SNMP_VIEW_EXCLUDED   2
Typedefs
typedef struct _viewEntry	VIEW_LIST
typedef struct _communityEntry	COMMUNITY_LIST
typedef int(	WMETHOD )(int, uint8_t *, uint8_t, size_t, OID *, size_t)
typedef struct _SNMPVAR	SNMPVAR
typedef struct _SNMP_VARLIST	SNMP_VARLIST
typedef struct _SUBTREE	SUBTREE
Functions
CONST uint8_t *	SnmpVarParse (CONST uint8_t *data, size_t *dlen, OID *name, size_t *nlen, uint8_t *type, uint8_t **value, size_t *vlen)
	Parse an SNMP variable.
uint8_t *	SnmpVarBuild (uint8_t *data, size_t *dlen, CONST OID *name, size_t nlen, uint8_t type, CONST uint8_t *value, size_t vlen)
	Build an SNMP variable.
int	SnmpAgentProcessRequest (SNMP_SESSION *sess, CONST uint8_t *in_data, size_t in_len, uint8_t *out_data, size_t *out_len)
	Parse incoming and create outgoing packet.
int	SnmpAgent (UDPSOCKET *sock)
	Run SNMP agent.
int	SnmpOidLenCmp (CONST OID *name1, CONST OID *name2, size_t len)
	Compare object identifiers up to a specified length.
int	SnmpOidCmp (CONST OID *name1, size_t len1, CONST OID *name2, size_t len2)
	Compare object identifiers.
int	SnmpOidTreeCmp (CONST OID *objid, size_t objlen, CONST OID *treeid, size_t treelen)
	Compare object identifier with tree element.
int	SnmpOidCmpIdx (CONST OID *name1, size_t len1, CONST OID *name2, size_t len2, OID index)
	Compare object identifiers with index added.
int	SnmpOidEquals (CONST OID *name1, size_t len1, CONST OID *name2, size_t len2)
void	SnmpStatsInc (int which)
uint32_t	SnmpStatsGet (int which)
void	SnmpStatsSet (int which, uint32_t value)
CONST uint8_t *	SnmpAuthParse (CONST uint8_t *data, size_t *length, uint8_t *sidp, size_t *slen, long *version)
	Parse header of community string based message.
uint8_t *	SnmpAuthBuild (SNMP_SESSION *session, uint8_t *data, size_t *length, size_t messagelen)
	Build header of community string based message.
int	SnmpViewCreate (CONST char *name, CONST OID *subtree, size_t subtreelen, int type)
int	SnmpViewFind (char *name)
int	SnmpCommunityFind (CONST char *name, int *readView, int *writeView)
	Find community entry by name.
int	SnmpCommunityCreate (CONST char *name, int readView, int writeView)
	Create a community entry.
int	SnmpMibRegister (OID basename[], size_t baselen, SNMPVAR *vars, int num)
	Register MIB variables.
uint8_t *	SnmpMibFind (OID *name, size_t *namelen, uint8_t *type, size_t *len, uint16_t *acl, int exact, WMETHOD **wmethod, int *no_obj)
	Find MIB variable.
SNMP_PDU *	SnmpPduCreate (int cmd, CONST OID *name, size_t nlen)
	Create PDU with a given type and object ID.
int	SnmpPduAddVariable (SNMP_PDU *pdu, OID *name, size_t nlen, uint8_t type, uint8_t *value, size_t vlen)
	Add variable to PDU.
void	SnmpPduDestroy (SNMP_PDU *pdu)
	Destroy PDU.
SNMP_SESSION *	SnmpSessionOpen (uint32_t ip, uint16_t port, uint8_t *id, size_t idlen)
	Open SNMP session.
void	SnmpSessionClose (SNMP_SESSION *session)
	Close SNMP session.
int	SnmpSessionSendPdu (SNMP_SESSION *session, SNMP_PDU *pdu)
	Send PDU.

---

Detailed Description

Simple network management protocol.

---

Define Documentation

#define SNMP_PORT   161

Standard UDP port for SNMP agents to receive requests messages.

Examples:

snmpd/snmpd.c.

Definition at line 56 of file snmp.h.

Referenced by main().

#define SNMP_TRAP_PORT   162

Standard UDP port for SNMP managers to receive notificaion messages.

Definition at line 62 of file snmp.h.

#define SNMP_MAX_LEN   500

Default maximum message size.

Definition at line 68 of file snmp.h.

Referenced by SnmpAgent(), and SnmpSessionSendPdu().

#define SNMP_VERSION_1   0

SNMPv1.

The original version, defined by RFC 1157.

Definition at line 75 of file snmp.h.

Referenced by SnmpAgentProcessRequest(), and SnmpAuthParse().

#define SNMP_VERSION_2C   1

SNMPv2c.

Community string-based SNMPv2, which was an attempt to combine the protocol operations of SNMPv2 with the security of SNMPv1, defined by RFCs 1901, 1905, and 1906.

Partly supplied by this code, work is in progress.

Definition at line 85 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_VERSION_3   3

SNMPv3.

An attempt by the IETF working group to merge the SNMPv2u and SNMPv2* proposals into a more widely accepted SNMPv3. The original version, defined by RFC 1157.

Not yet supported by this code.

Definition at line 95 of file snmp.h.

#define SNMP_MSG_GET   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x0)

Definition at line 100 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MSG_GETNEXT   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x1)

Definition at line 101 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MSG_RESPONSE   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x2)

Definition at line 102 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MSG_SET   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x3)

Definition at line 103 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MSG_TRAP   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x4)

Definition at line 108 of file snmp.h.

Referenced by SnmpSessionSendPdu().

#define SNMP_MSG_GETBULK   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x5)

Definition at line 113 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MSG_INFORM   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x6)

Definition at line 114 of file snmp.h.

#define SNMP_MSG_TRAP2   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x7)

Definition at line 115 of file snmp.h.

#define SNMP_MSG_REPORT   (ASN_CONTEXT | ASN_CONSTRUCTOR | 0x8)

Definition at line 120 of file snmp.h.

#define SNMP_NOSUCHOBJECT   (ASN_CONTEXT | ASN_PRIMITIVE | 0x0)

Definition at line 125 of file snmp.h.

Referenced by SnmpVarBuild().

#define SNMP_NOSUCHINSTANCE   (ASN_CONTEXT | ASN_PRIMITIVE | 0x1)

Definition at line 126 of file snmp.h.

Referenced by SnmpVarBuild().

#define SNMP_ENDOFMIBVIEW   (ASN_CONTEXT | ASN_PRIMITIVE | 0x2)

Definition at line 127 of file snmp.h.

Referenced by SnmpVarBuild().

#define SNMP_ERR_NOERROR   0

Definition at line 132 of file snmp.h.

#define SNMP_ERR_TOOBIG   1

Definition at line 133 of file snmp.h.

#define SNMP_ERR_NOSUCHNAME   2

Definition at line 134 of file snmp.h.

#define SNMP_ERR_BADVALUE   3

Definition at line 135 of file snmp.h.

#define SNMP_ERR_READONLY   4

Definition at line 136 of file snmp.h.

#define SNMP_ERR_GENERR   5

Definition at line 137 of file snmp.h.

#define SNMP_ERR_NOACCESS   6

Definition at line 142 of file snmp.h.

#define SNMP_ERR_WRONGTYPE   7

Definition at line 143 of file snmp.h.

#define SNMP_ERR_WRONGLENGTH   8

Definition at line 144 of file snmp.h.

#define SNMP_ERR_WRONGENCODING   9

Definition at line 145 of file snmp.h.

#define SNMP_ERR_WRONGVALUE   10

Definition at line 146 of file snmp.h.

#define SNMP_ERR_NOCREATION   11

Definition at line 147 of file snmp.h.

#define SNMP_ERR_INCONSISTENTVALUE   12

Definition at line 148 of file snmp.h.

#define SNMP_ERR_RESOURCEUNAVAILABLE   13

Definition at line 149 of file snmp.h.

#define SNMP_ERR_COMMITFAILED   14

Definition at line 150 of file snmp.h.

#define SNMP_ERR_UNDOFAILED   15

Definition at line 151 of file snmp.h.

#define SNMP_ERR_AUTHORIZATIONERROR   16

Definition at line 152 of file snmp.h.

#define SNMP_ERR_NOTWRITABLE   17

Definition at line 153 of file snmp.h.

#define SNMP_ERR_INCONSISTENTNAME   18

Definition at line 154 of file snmp.h.

#define SNMP_TRAP_COLDSTART   0

Definition at line 159 of file snmp.h.

#define SNMP_TRAP_WARMSTART   1

Definition at line 160 of file snmp.h.

#define SNMP_TRAP_LINKDOWN   2

Definition at line 161 of file snmp.h.

#define SNMP_TRAP_LINKUP   3

Definition at line 162 of file snmp.h.

#define SNMP_TRAP_AUTHFAIL   4

Definition at line 163 of file snmp.h.

#define SNMP_TRAP_EGPNEIGHBORLOSS   5

Definition at line 164 of file snmp.h.

#define SNMP_TRAP_ENTERPRISESPECIFIC   6

Definition at line 165 of file snmp.h.

#define SNMP_OID_INTERNET   1, 3, 6, 1

Examples:

snmpd/snmpd.c.

Definition at line 170 of file snmp.h.

Referenced by main().

#define SNMP_OID_ENTERPRISES   SNMP_OID_INTERNET, 4, 1

Definition at line 171 of file snmp.h.

#define SNMP_OID_MIB2   SNMP_OID_INTERNET, 2, 1

Definition at line 172 of file snmp.h.

#define SNMP_OID_SNMPV2   SNMP_OID_INTERNET, 6

Definition at line 173 of file snmp.h.

#define SNMP_OID_SNMPMODULES   SNMP_OID_SNMPV2, 3

Definition at line 174 of file snmp.h.

#define SNMP_PARSE_ERROR   -1

Definition at line 178 of file snmp.h.

#define SNMP_BUILD_ERROR   -2

Definition at line 179 of file snmp.h.

#define MAX_SID_LEN   32

Maximum length of a community name.

Definition at line 182 of file snmp.h.

#define MAX_NAME_LEN   128

Maximum number of sub IDs in an OID.

Definition at line 184 of file snmp.h.

#define SNMP_ACT_RESERVE1   0

Definition at line 186 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_ACT_RESERVE2   1

Definition at line 187 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_ACT_COMMIT   2

Definition at line 188 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_ACT_ACTION   3

Definition at line 189 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_ACT_FREE   4

Definition at line 190 of file snmp.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_MAX_MSG_SIZE   1472

Examples:

snmpd/snmpd.c.

Definition at line 53 of file snmp_api.h.

Referenced by main().

#define SNMP_STAT_INPKTS   0

Definition at line 59 of file snmp_api.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_STAT_OUTPKTS   1

Definition at line 60 of file snmp_api.h.

Referenced by SnmpAgent().

#define SNMP_STAT_INBADVERSIONS   2

Definition at line 61 of file snmp_api.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_STAT_INBADCOMMUNITYNAMES   3

Definition at line 62 of file snmp_api.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_STAT_INBADCOMMUNITYUSES   4

Definition at line 63 of file snmp_api.h.

#define SNMP_STAT_INASNPARSEERRS   5

Definition at line 64 of file snmp_api.h.

Referenced by SnmpAgentProcessRequest().

#define SNMP_STAT_INTOOBIGS   6

Definition at line 65 of file snmp_api.h.

#define SNMP_STAT_INNOSUCHNAMES   7

Definition at line 66 of file snmp_api.h.

#define SNMP_STAT_INBADVALUES   8

Definition at line 67 of file snmp_api.h.

#define SNMP_STAT_INREADONLYS   9

Definition at line 68 of file snmp_api.h.

#define SNMP_STAT_INGENERRS   10

Definition at line 69 of file snmp_api.h.

#define SNMP_STAT_INTOTALREQVARS   11

Definition at line 70 of file snmp_api.h.

#define SNMP_STAT_INTOTALSETVARS   12

Definition at line 71 of file snmp_api.h.

#define SNMP_STAT_INGETREQUESTS   13

Definition at line 72 of file snmp_api.h.

#define SNMP_STAT_INGETNEXTS   14

Definition at line 73 of file snmp_api.h.

#define SNMP_STAT_INSETREQUESTS   15

Definition at line 74 of file snmp_api.h.

#define SNMP_STAT_INGETRESPONSES   16

Definition at line 75 of file snmp_api.h.

#define SNMP_STAT_INTRAPS   17

Definition at line 76 of file snmp_api.h.

#define SNMP_STAT_OUTTOOBIGS   18

Definition at line 77 of file snmp_api.h.

Referenced by SnmpVarBuild().

#define SNMP_STAT_OUTNOSUCHNAMES   19

Definition at line 78 of file snmp_api.h.

#define SNMP_STAT_OUTBADVALUES   20

Definition at line 79 of file snmp_api.h.

Referenced by SnmpVarBuild().

#define SNMP_STAT_OUTGENERRS   21

Definition at line 80 of file snmp_api.h.

#define SNMP_STAT_OUTGETREQUESTS   22

Definition at line 81 of file snmp_api.h.

#define SNMP_STAT_OUTGETNEXTS   23

Definition at line 82 of file snmp_api.h.

#define SNMP_STAT_OUTSETREQUESTS   24

Definition at line 83 of file snmp_api.h.

#define SNMP_STAT_OUTGETRESPONSES   25

Definition at line 84 of file snmp_api.h.

#define SNMP_STAT_OUTTRAPS   26

Definition at line 85 of file snmp_api.h.

#define SNMP_STAT_ENABLEAUTHENTRAPS   27

Definition at line 86 of file snmp_api.h.

#define SNMP_STAT_MAX   28

Definition at line 88 of file snmp_api.h.

Referenced by SnmpStatsGet(), SnmpStatsInc(), and SnmpStatsSet().

#define SNMP_VIEW_INCLUDED   1

Examples:

snmpd/snmpd.c.

Definition at line 56 of file snmp_config.h.

Referenced by main().

#define SNMP_VIEW_EXCLUDED   2

Definition at line 57 of file snmp_config.h.

---

Typedef Documentation

typedef struct _viewEntry VIEW_LIST

typedef struct _communityEntry COMMUNITY_LIST

typedef int( WMETHOD)(int, uint8_t *, uint8_t, size_t, OID *, size_t)

Definition at line 53 of file snmp_mib.h.

typedef struct _SNMPVAR SNMPVAR

typedef struct _SNMP_VARLIST SNMP_VARLIST

Definition at line 54 of file snmp_pdu.h.

typedef struct _SUBTREE SUBTREE

---

Function Documentation

CONST uint8_t* SnmpVarParse	(	CONST uint8_t *	data,
		size_t *	dlen,
		OID *	name,
		size_t *	nlen,
		uint8_t *	type,
		uint8_t **	value,
		size_t *	vlen
	)

Parse an SNMP variable.

Parameters:

data	Pointer to start of the name/value pair.
dlen	Contains the number of valid bytes following the start of the variable. On exit, it is returned as the number of valid bytes following the end of this variable.
name	Pointer to a buffer that receives the name (OID).
nlen	On entry, this contains the maximum number of sub IDs accepted for the name. On exit, it is returned as the actual number sub IDs found in the name.
type	Pointer to the variable that receives the ASN type of the value.
value	Pointer to variable that receives a pointer to the ASN1 encoded value of variable.
vlen	Pointer to the variable that receives the length of the value.

Returns:

Pointer to the first byte past the end of this name/value pair. Returns NULL on any error.

Definition at line 65 of file snmp.c.

References ASN_CONSTRUCTOR, ASN_OBJECT_ID, ASN_PRIMITIVE, ASN_SEQUENCE, ASN_UNIVERSAL, AsnHeaderParse(), AsnOidParse(), AsnSequenceParse(), and CONST.

Here is the call graph for this function:

uint8_t* SnmpVarBuild	(	uint8_t *	data,
		size_t *	dlen,
		CONST OID *	name,
		size_t	nlen,
		uint8_t	type,
		CONST uint8_t *	value,
		size_t	vlen
	)

Build an SNMP variable.

Parameters:

data	Pointer to start of the output buffer.
dlen	Contains the number of valid bytes following the start of the variable. On exit, it is returned as the number of valid bytes following the end of this variable.
name	Name (OID).
nlen	Number of sub IDs of the name.
type	ASN type of the value.
value	Pointer to the value.
vlen	Length of the value.

Returns:

Pointer to the first byte past the end of this name/value pair. Returns NULL on any error.

Definition at line 114 of file snmp.c.

References ASN_BIT_STR, ASN_CONSTRUCTOR, ASN_COUNTER, ASN_COUNTER64, ASN_GAUGE, ASN_INTEGER, ASN_IPADDRESS, ASN_NSAP, ASN_NULL, ASN_OBJECT_ID, ASN_OCTET_STR, ASN_OPAQUE, ASN_PRIMITIVE, ASN_SEQUENCE, ASN_TIMETICKS, ASN_UINTEGER, ASN_UNIVERSAL, AsnBitStringBuild(), AsnIntegerBuild(), AsnNullBuild(), AsnOctetStringBuild(), AsnOidBuild(), AsnSequenceBuild(), AsnUnsigned64Build(), AsnUnsignedBuild(), SNMP_ENDOFMIBVIEW, SNMP_NOSUCHINSTANCE, SNMP_NOSUCHOBJECT, SNMP_STAT_OUTBADVALUES, SNMP_STAT_OUTTOOBIGS, and SnmpStatsInc().

Here is the call graph for this function:

int SnmpAgentProcessRequest	(	SNMP_SESSION *	sess,
		CONST uint8_t *	in_data,
		size_t	in_len,
		uint8_t *	out_data,
		size_t *	out_len
	)

Parse incoming and create outgoing packet.

Parameters:

in_data	Pointer to the incoming packet.
in_len	Number of valid bytes in the incoming packet.
out_data	Pointer to a buffer for the outgoing packet.
out_len	Pointer to the variable that receives the number of bytes in the outgoing packet.
out_len	Pointer to a variable which contains the size of the output buffer on entry. On exit, it is returned as the number of valid bytes in the output buffer.

Returns:

0 upon success and -1 upon failure.

Definition at line 307 of file snmp_agent.c.

References ASN_INTEGER, ASN_PRIMITIVE, ASN_UNIVERSAL, AsnHeaderParse(), AsnIntegerBuild(), AsnIntegerParse(), AsnSequenceBuild(), CONST, SNMP_SESSION::sess_id, SNMP_SESSION::sess_id_len, SNMP_SESSION::sess_read_view, SNMP_SESSION::sess_version, SNMP_SESSION::sess_write_view, SNMP_ACT_ACTION, SNMP_ACT_COMMIT, SNMP_ACT_FREE, SNMP_ACT_RESERVE1, SNMP_ACT_RESERVE2, SNMP_MSG_GET, SNMP_MSG_GETBULK, SNMP_MSG_GETNEXT, SNMP_MSG_RESPONSE, SNMP_MSG_SET, SNMP_STAT_INASNPARSEERRS, SNMP_STAT_INBADCOMMUNITYNAMES, SNMP_STAT_INBADVERSIONS, SNMP_STAT_INPKTS, SNMP_VERSION_1, SNMP_VERSION_2C, SnmpAuthBuild(), SnmpAuthParse(), SnmpCommunityFind(), and SnmpStatsInc().

Referenced by SnmpAgent().

Here is the call graph for this function:

int SnmpAgent

(

UDPSOCKET *

sock

)

Run SNMP agent.

Normally runs in an endless loop, which is only left in case of an error.

Parameters:

sock	UDP socket to use.

Returns:

Always -1.

Definition at line 468 of file snmp_agent.c.

References free(), malloc(), memset(), NutUdpReceiveFrom(), NutUdpSendTo(), SNMP_MAX_LEN, SNMP_STAT_OUTPKTS, SnmpAgentProcessRequest(), and SnmpStatsInc().

Referenced by main().

Here is the call graph for this function:

int SnmpOidLenCmp	(	CONST OID *	name1,
		CONST OID *	name2,
		size_t	len
	)

Compare object identifiers up to a specified length.

Parameters:

name1	First object identifier.
name2	Second object identifier.
len	Number of sub identifiers to compare.

Definition at line 56 of file snmp_api.c.

Referenced by SnmpOidCmp(), SnmpOidCmpIdx(), and SnmpOidTreeCmp().

int SnmpOidCmp	(	CONST OID *	name1,
		size_t	len1,
		CONST OID *	name2,
		size_t	len2
	)

Compare object identifiers.

Parameters:

name1	First object identifier.
len1	Length of first object identifier.
name2	Second object identifier.
len2	Length of second object identifier.

Returns:

0 if both are equal, 1 if first element is larger or -1 if first element is lower than the second one.

Definition at line 84 of file snmp_api.c.

References SnmpOidLenCmp().

Referenced by SnmpMibRegister().

Here is the call graph for this function:

int SnmpOidTreeCmp	(	CONST OID *	objid,
		size_t	objlen,
		CONST OID *	treeid,
		size_t	treelen
	)

Compare object identifier with tree element.

Parameters:

name1	Object identifier.
len1	Length of object identifier.
name2	Tree identifier.
len2	Length of tree identifier.

Returns:

0 if the object identifier is part of the subtree, -1 if it is located before the tree element or 1 if it is located after the tree element.

Definition at line 111 of file snmp_api.c.

References SnmpOidLenCmp().

Referenced by SnmpMibFind().

Here is the call graph for this function:

int SnmpOidCmpIdx	(	CONST OID *	name1,
		size_t	len1,
		CONST OID *	name2,
		size_t	len2,
		OID	index
	)

Compare object identifiers with index added.

Parameters:

name1	First object identifier.
len1	Length of first object identifier.
name2	Second object identifier.
len2	Length of second object identifier.
index	Index sub identifier.

Returns:

0 if both are equal, 1 if first element is larger or -1 if first element is lower than the second one.

Definition at line 134 of file snmp_api.c.

References SnmpOidLenCmp().

Here is the call graph for this function:

int SnmpOidEquals	(	CONST OID *	name1,
		size_t	len1,
		CONST OID *	name2,
		size_t	len2
	)

Definition at line 172 of file snmp_api.c.

References memcmp().

Here is the call graph for this function:

void SnmpStatsInc

(

int

which

)

Definition at line 181 of file snmp_api.c.

References SNMP_STAT_MAX.

Referenced by SnmpAgent(), SnmpAgentProcessRequest(), and SnmpVarBuild().

uint32_t SnmpStatsGet

(

int

which

)

Definition at line 188 of file snmp_api.c.

References SNMP_STAT_MAX.

void SnmpStatsSet	(	int	which,
		uint32_t	value
	)

Definition at line 196 of file snmp_api.c.

References SNMP_STAT_MAX.

CONST uint8_t* SnmpAuthParse	(	CONST uint8_t *	data,
		size_t *	length,
		uint8_t *	sidp,
		size_t *	slen,
		long *	version
	)

Parse header of community string based message.

Retrieves version and community.

Parameters:

data	Points to the message.
length	Bytes left in message.
sidp	Pointer to a buffer that receives the community string.
slen	Length of the community string.
version	Message version

Definition at line 54 of file snmp_auth.c.

References ASN_CONSTRUCTOR, ASN_SEQUENCE, AsnIntegerParse(), AsnOctetStringParse(), AsnSequenceParse(), and SNMP_VERSION_1.

Referenced by SnmpAgentProcessRequest().

Here is the call graph for this function:

uint8_t* SnmpAuthBuild	(	SNMP_SESSION *	session,
		uint8_t *	data,
		size_t *	length,
		size_t	messagelen
	)

Build header of community string based message.

Definition at line 81 of file snmp_auth.c.

References ASN_CONSTRUCTOR, ASN_INTEGER, ASN_OCTET_STR, ASN_PRIMITIVE, ASN_SEQUENCE, ASN_UNIVERSAL, AsnIntegerBuild(), AsnOctetStringBuild(), AsnSequenceBuild(), SNMP_SESSION::sess_id, SNMP_SESSION::sess_id_len, and SNMP_SESSION::sess_version.

Referenced by SnmpAgentProcessRequest().

Here is the call graph for this function:

int SnmpViewCreate	(	CONST char *	name,
		CONST OID *	subtree,
		size_t	subtreelen,
		int	type
	)

Parameters:

name	Symbolic name of this view.
type	Either SNMP_VIEW_INCLUDED or SNMP_VIEW_EXCLUDED.

Returns:

View index on success. Otherwise -1 is returned.

Definition at line 56 of file snmp_config.c.

References malloc(), memset(), _viewEntry::next, strcmp(), strcpy(), strlen(), _viewEntry::view_index, _viewEntry::view_name, _viewEntry::view_subtree, _viewEntry::view_subtree_len, and _viewEntry::view_type.

Referenced by main().

Here is the call graph for this function:

int SnmpViewFind

(

char *

name

)

Definition at line 98 of file snmp_config.c.

References _viewEntry::next, strcmp(), _viewEntry::view_index, and _viewEntry::view_name.

Here is the call graph for this function:

int SnmpCommunityFind	(	CONST char *	name,
		int *	readView,
		int *	writeView
	)

Find community entry by name.

Parameters:

name	Community name.
readView	Pointer to a variable that receives the view index for read access.
writeView	Pointer to a variable that receives the view index for write access.

Returns:

0 on success, -1 otherwise.

Definition at line 124 of file snmp_config.c.

References _communityEntry::comm_name, _communityEntry::comm_read_view, _communityEntry::comm_write_view, _communityEntry::next, and strcmp().

Referenced by SnmpAgentProcessRequest().

Here is the call graph for this function:

int SnmpCommunityCreate	(	CONST char *	name,
		int	readView,
		int	writeView
	)

Create a community entry.

Parameters:

name	Community name.
readView	View index for read access, obtained from a previous call to SnmpViewCreate().
writeView	View index for write access, obtained from a previous call to SnmpViewCreate().

Returns:

0 on success, -1 otherwise.

Definition at line 153 of file snmp_config.c.

References _communityEntry::comm_name, _communityEntry::comm_read_view, _communityEntry::comm_write_view, malloc(), memset(), _communityEntry::next, strcmp(), strcpy(), and strlen().

Referenced by main().

Here is the call graph for this function:

int SnmpMibRegister	(	OID	basename[],
		size_t	baselen,
		SNMPVAR *	vars,
		int	num
	)

Register MIB variables.

Definition at line 75 of file snmp_mib.c.

References malloc(), memcpy(), SnmpOidCmp(), _SUBTREE::sub_name, _SUBTREE::sub_namelen, _SUBTREE::sub_next, _SUBTREE::sub_numvars, and _SUBTREE::sub_vars.

Referenced by MibRegisterIfVars(), and MibRegisterSysVars().

Here is the call graph for this function:

uint8_t* SnmpMibFind	(	OID *	name,
		size_t *	namelen,
		uint8_t *	type,
		size_t *	len,
		uint16_t *	acl,
		int	exact,
		WMETHOD **	wmethod,
		int *	no_obj
	)

Find MIB variable.

Parameters:

name
namelen
type
len
acl
exact
wmethod
no_obj

Definition at line 114 of file snmp_mib.c.

References access(), free(), malloc(), memcpy(), SnmpOidTreeCmp(), _SUBTREE::sub_name, _SUBTREE::sub_namelen, _SUBTREE::sub_next, _SUBTREE::sub_numvars, _SUBTREE::sub_vars, _SNMPVAR::var_acl, _SNMPVAR::var_get, _SNMPVAR::var_name, _SNMPVAR::var_namelen, and _SNMPVAR::var_type.

Here is the call graph for this function:

SNMP_PDU* SnmpPduCreate	(	int	cmd,
		CONST OID *	name,
		size_t	nlen
	)

Create PDU with a given type and object ID.

Parameters:

cmd	PDU type.
name	Object identifier.
nlen	Number of sub IDs of the object identifier.

Definition at line 53 of file snmp_pdu.c.

References calloc, free(), malloc(), memcpy(), SNMP_PDU::pdu_cmd, SNMP_PDU::pdu_enterprise, and SNMP_PDU::pdu_enterprise_length.

Here is the call graph for this function:

int SnmpPduAddVariable	(	SNMP_PDU *	pdu,
		OID *	name,
		size_t	nlen,
		uint8_t	type,
		uint8_t *	value,
		size_t	vlen
	)

Add variable to PDU.

Parameters:

pdu	Pointer to the PDU.
name	Variable name.
nlen	Number of sub IDs of the variable name.
type	Variable type.
value	Pointer to the variable's value.
vlen	Length of the variable value in byts.

Definition at line 83 of file snmp_pdu.c.

References ASN_COUNTER, ASN_GAUGE, ASN_INTEGER, ASN_TIMETICKS, ASN_UINTEGER, calloc, free(), malloc(), memcpy(), SNMP_PDU::pdu_variables, _SNMP_VARLIST::var_name, _SNMP_VARLIST::var_next, _SNMP_VARLIST::var_nlen, _SNMP_VARLIST::var_type, _SNMP_VARLIST::var_val, _SNMP_VARLIST::var_vlen, and _SNMP_VARLIST::var_vptr.

Here is the call graph for this function:

void SnmpPduDestroy

(

SNMP_PDU *

pdu

)

Destroy PDU.

Parameters:

pdu	Pointer to the PDU info, obtained by a call to SnmpPduCreate().

Definition at line 137 of file snmp_pdu.c.

References free(), SNMP_PDU::pdu_enterprise, SNMP_PDU::pdu_variables, _SNMP_VARLIST::var_name, _SNMP_VARLIST::var_next, _SNMP_VARLIST::var_val, and _SNMP_VARLIST::var_vptr.

Here is the call graph for this function:

SNMP_SESSION* SnmpSessionOpen	(	uint32_t	ip,
		uint16_t	port,
		uint8_t *	id,
		size_t	idlen
	)

Open SNMP session.

Parameters:

ip	Remote IP address.
port	Remote port number.
id	Community name.
idlen	Length of the community name.

Returns:

Pointer to a newly created session info.

Definition at line 61 of file snmp_session.c.

References calloc, free(), memcpy(), NutUdpCreateSocket(), SNMP_SESSION::sess_id, SNMP_SESSION::sess_id_len, SNMP_SESSION::sess_rem_addr, SNMP_SESSION::sess_rem_port, and SNMP_SESSION::sess_sock.

Here is the call graph for this function:

void SnmpSessionClose

(

SNMP_SESSION *

session

)

Close SNMP session.

Parameters:

session

Points to the session info, obtained by calling SnmpSessionOpen().

Definition at line 90 of file snmp_session.c.

References free(), NutUdpDestroySocket(), and SNMP_SESSION::sess_sock.

Here is the call graph for this function:

int SnmpSessionSendPdu	(	SNMP_SESSION *	session,
		SNMP_PDU *	pdu
	)

Send PDU.

Parameters:

session	Points to the session info, obtained by calling SnmpSessionOpen().
pdu	Points to the PDU info, obtained by calling SnmpPduCreate().

Returns:

0 on success, -1 otherwise.

Definition at line 256 of file snmp_session.c.

References free(), malloc(), NutUdpSendTo(), SNMP_PDU::pdu_cmd, SNMP_PDU::pdu_reqid, SNMP_SESSION::sess_rem_addr, SNMP_SESSION::sess_rem_port, SNMP_SESSION::sess_sock, SNMP_MAX_LEN, and SNMP_MSG_TRAP.

Here is the call graph for this function:
