Realtek RTL8019AS

10 MBit NE2000 compatible controller. More...

Collaboration diagram for Realtek RTL8019AS:

Data Structures
struct	nic_pkt_header
Modules
	Device eth0
	Realtek 8019AS Ethernet device.
Defines
#define	NICINB(reg)   (*((volatile uint8_t *)RTL_BASE_ADDR + reg))
#define	NICOUTB(reg, val)   (*((volatile uint8_t *)RTL_BASE_ADDR + reg) = val)
Functions
void	NicRx (void *arg)
	NIC receiver thread.
int	NicOutput (NUTDEVICE *dev, NETBUF *nb)
	Send Ethernet packet.
int	NicInit (NUTDEVICE *dev)
	Initialize Ethernet hardware.

---

Detailed Description

10 MBit NE2000 compatible controller.

The RTL8019AS chip is used on the Ethernut 1 board.

---

Define Documentation

#define NICINB

(

reg

)

(*((volatile uint8_t *)RTL_BASE_ADDR + reg))

Definition at line 388 of file nicrtl.c.

#define NICOUTB	(		reg,
			val
	)		(*((volatile uint8_t *)RTL_BASE_ADDR + reg) = val)

Definition at line 389 of file nicrtl.c.

---

Function Documentation

NicRx

(

void *

arg

)

NIC receiver thread.

It runs with high priority.

Definition at line 1287 of file nicrtl.c.

References cbi, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, ifnet::if_mac, ifnet::if_recv, NICINFO::ni_rx_packets, NICINFO::ni_rx_rdy, NutEventWait(), NutSleep(), NutThreadSetPriority(), RTL_SIGNAL_IRQ, and sbi.

Referenced by NicInit().

Here is the call graph for this function:

int NicOutput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Send Ethernet packet.

Parameters:

dev	Identifies the device to use.
nb	Network buffer structure containing the packet to be sent. The structure must have been allocated by a previous call NutNetBufAlloc().

Returns:

0 on success, -1 in case of any errors.

Definition at line 1344 of file nicrtl.c.

References _NUTDEVICE::dev_dcb, and NICINFO::ni_tx_packets.

int NicInit

(

NUTDEVICE *

dev

)

Initialize Ethernet hardware.

Resets RTL8019AS Ethernet controller, initializes all required hardware registers and starts a background thread for incoming Ethernet traffic.

Applications should do not directly call this function. It is automatically executed during during device registration by NutRegisterDevice(). Note, that base address and interrupt number passed to NutRegisterDevice() are silently ignored by this driver for performance reasons. These values can be changed only by using the Nut/OS Configurator to rebuild the system.

If the network configuration hasn't been set by the application before registering the specified device, this function will call NutNetLoadConfig() to get the MAC address.

Parameters:

dev	Identifies the device to initialize.

Definition at line 1376 of file nicrtl.c.

References cbi, _CONFNET::cd_size, _CONFNET::cdn_mac, confnet, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _NUTDEVICE::dev_name, ifnet::if_mac, memcpy(), memset(), NicRx(), NUT_THREAD_NICRXSTACK, NUT_THREAD_STACK_ADD, NUT_THREAD_STACK_MULT, NutNetLoadConfig(), NutRegisterIrqHandler(), NutSleep(), NutThreadCreate(), RTL_RISING_EDGE_MODE, RTL_SIGNAL, RTL_SIGNAL_IRQ, sbi, and WAIT500.

Here is the call graph for this function:
