XgNicDm9000

Functions
void	NicRxLanc (void *arg)
int	DmOutput (NUTDEVICE *dev, NETBUF *nb)
	Send Ethernet packet.
int	DmInit (NUTDEVICE *dev)
	Initialize Ethernet hardware.
Variables
NUTDEVICE	devDm9000
	Device information structure.

---

Function Documentation

void NicRxLanc

(

void *

arg

)

Definition at line 830 of file dm9000.c.

References _BV, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, ETHER_IS_BROADCAST, ETHER_IS_ZERO, ifnet::if_mac, ifnet::if_recv, IRQ0_ID, _NETBUF::nb_dl, NICINFO::ni_rx_rdy, NIC_SIGNAL, NIC_SIGNAL_BIT, NIC_SIGNAL_PDR, NIC_SIGNAL_XSR, NUT_IRQMODE_HIGHLEVEL, NutEventPost(), NutEventWait(), NutIrqEnable(), NutIrqSetMode(), NutNetBufFree(), NutSleep(), NutThreadSetPriority(), outr, PMC_PCER, and _NBDATA::sz.

Here is the call graph for this function:

int DmOutput	(	NUTDEVICE *	dev,
		NETBUF *	nb
	)

Send Ethernet packet.

Parameters:

dev	Identifies the device to use.
nb	Network buffer structure containing the packet to be sent. The structure must have been allocated by a previous call NutNetBufAlloc().

Returns:

0 on success, -1 in case of any errors.

Definition at line 928 of file dm9000.c.

References _NUTDEVICE::dev_dcb, NICINFO::ni_tx_rdy, NutEventPost(), and NutEventWait().

Here is the call graph for this function:

int DmInit

(

NUTDEVICE *

dev

)

Initialize Ethernet hardware.

Resets the LAN91C111 Ethernet controller, initializes all required hardware registers and starts a background thread for incoming Ethernet traffic.

Applications should do not directly call this function. It is automatically executed during during device registration by NutRegisterDevice().

If the network configuration hasn't been set by the application before registering the specified device, this function will call NutNetLoadConfig() to get the MAC address.

Parameters:

dev	Identifies the device to initialize.

Definition at line 988 of file dm9000.c.

References _NUTDEVICE::dev_dcb, memset(), NIC_ISR, NIC_ISR_IOM, NIC_ISR_M32, NIC_PID, NIC_SIGNAL, NIC_VID, NicRxLanc(), NUT_THREAD_NICRXSTACK, NUT_THREAD_STACK_ADD, NUT_THREAD_STACK_MULT, NutRegisterIrqHandler(), and NutThreadCreate().

Here is the call graph for this function:

---

Variable Documentation

NUTDEVICE devDm9000

Initial value:

 {
    0,
    {'e', 't', 'h', '0', 0, 0, 0, 0, 0},
    IFTYP_NET,
    0,
    0,
    &ifn_eth0,
    &dcb_eth0,
    DmInit,
    DmIOCtl,
    0,
    0,

    0,

    0,
    0,
    0
}

Device information structure.

A pointer to this structure must be passed to NutRegisterDevice() to bind this Ethernet device driver to the Nut/OS kernel. An application may then call NutNetIfConfig() with the name eth0 of this driver to initialize the network interface.

Definition at line 1183 of file dm9000.c.
