Standard I/O

Standard stream interface to Nut/OS devices. More...

Collaboration diagram for Standard I/O:

Defines
#define	EOF   (-1)
	End of file.
#define	_IOFBF   0x00
	Fully buffered.
#define	_IOLBF   0x01
	Line buffered.
#define	_IONBF   0x02
	Unbuffered.
#define	stdin   (__iob[0])
	Standard input stream.
#define	stdout   (__iob[1])
	Standard output stream.
#define	stderr   (__iob[2])
	Standard error output stream.
#define	CF_LONG   0x01
#define	CF_SUPPRESS   0x02
#define	CF_SIGNOK   0x04
#define	CF_NDIGITS   0x08
#define	CF_PFXOK   0x10
#define	CF_NZDIGITS   0x20
#define	CF_DPTOK   0x10
#define	CF_EXPOK   0x20
#define	CT_CHAR   0
#define	CT_STRING   2
#define	CT_INT   3
#define	CT_FLOAT   4
#define	BUF   16
#define	PADSIZE   16
#define	ALT   0x01
#define	LADJUST   0x04
#define	LONGINT   0x08
#define	ZEROPAD   0x10
Typedefs
typedef struct __iobuf	FILE
	Stream structure type.
Functions
void	clearerr (FILE *stream)
	Reset error status of a stream.
int	fclose (FILE *stream)
	Close a stream.
void	fcloseall (void)
	Close all open streams.
FILE *	_fdopen (int fd, CONST char *mode)
	Open a stream associated with a file, device or socket descriptor.
int	feof (FILE *stream)
	Test if a stream reached the end of file.
int	ferror (FILE *stream)
	Test for an error on a stream.
int	fflush (FILE *stream)
	Flush a stream.
int	fgetc (FILE *stream)
	Read a character from a stream.
char *	fgets (char *buffer, int count, FILE *stream)
	Read a line from a stream.
int	_fileno (FILE *stream)
	Get the file descriptor associated with a stream.
void	_flushall (void)
	Flushes all streams.
int	_fmode (CONST char *mode)
FILE *	fopen (CONST char *name, CONST char *mode)
	Open a stream.
int	fprintf (FILE *stream, CONST char *fmt,...)
	Print formatted data to a stream.
int	fprintf_P (FILE *stream, PGM_P fmt,...)
	Print formatted data to a stream.
int	fpurge (FILE *stream)
	Purge a stream, i.e. discards the input buffer.
int	fputc (int c, FILE *stream)
	Write a character to a stream.
int	fputs (CONST char *string, FILE *stream)
	Write a string to a stream.
int	fputs_P (PGM_P string, FILE *stream)
	Write a string from progam memory to a stream.
size_t	fread (void *buffer, size_t size, size_t count, FILE *stream)
	Read data from a stream.
FILE *	freopen (CONST char *name, CONST char *mode, FILE *stream)
	Reassign a stream.
int	fscanf (FILE *stream, CONST char *fmt,...)
	Read formatted data from a stream.
int	fscanf_P (FILE *stream, PGM_P fmt,...)
	Read formatted data from a stream.
int	fseek (FILE *stream, long offset, int origin)
	Move read/write position of a stream.
long	ftell (FILE *stream)
	Return the read/write position of a stream.
size_t	fwrite (CONST void *data, size_t size, size_t count, FILE *stream)
	Write data to a stream.
size_t	fwrite_P (PGM_P data, size_t size, size_t count, FILE *stream)
	Write data from program space to a stream.
int	getc (FILE *stream)
	Read a character from a stream.
int	getchar (void)
	Read a character from a standard input.
int	_getf (int _getb(int, void *, size_t), int fd, CONST char *fmt, va_list ap)
	Read formatted data using a given input function.
char *	gets (char *buffer)
	Get a line from the standard input stream.
int	printf (CONST char *fmt,...)
	Print formatted data to the standard output stream.
int	printf_P (PGM_P fmt,...)
	Print formatted output to the standard output stream.
int	putc (int c, FILE *stream)
	Write a character to a stream.
int	putchar (int c)
	Write a character to standard output.
int	_putf (int _putb(int, CONST void *, size_t), int fd, CONST char *fmt, va_list ap)
	Write formatted data using a given output function.
int	puts (CONST char *string)
	Write a string to stdout.
int	puts_P (PGM_P string)
	Write a string from program memory to stdout.
int	scanf (CONST char *fmt,...)
	Read formatted data from the standard input stream.
int	scanf_P (PGM_P fmt,...)
	Read formatted data from the standard input stream.
int	sprintf (char *buffer, CONST char *fmt,...)
	Write formatted data to a string.
int	sprintf_P (char *buffer, PGM_P fmt,...)
	Write formatted data to a string.
int	sscanf (CONST char *string, CONST char *fmt,...)
	Read formatted data from a string.
int	sscanf_P (CONST char *string, CONST char *fmt,...)
	Read formatted data from a string.
int	ungetc (int c, FILE *stream)
	Push a character back onto a stream.
int	vfprintf (FILE *stream, CONST char *fmt, va_list ap)
	Write argument list to a stream using a given format.
int	vfprintf_P (FILE *stream, PGM_P fmt, va_list ap)
	Write argument list to a stream using a given format.
int	vfscanf (FILE *stream, CONST char *fmt, va_list ap)
	Read formatted data from a stream.
int	vfscanf_P (FILE *stream, PGM_P fmt, va_list ap)
	Read formatted data from a stream.
int	vsprintf (char *buffer, CONST char *fmt, va_list ap)
	Write argument list to a string using a given format.
int	vsprintf_P (char *buffer, PGM_P fmt, va_list ap)
	Write argument list to a string using a given format.
int	vsscanf (CONST char *string, CONST char *fmt, va_list ap)
	Read formatted data from a string.
int	vsscanf_P (CONST char *string, PGM_P fmt, va_list ap)
	Read formatted data from a string.
Variables
FILE *	__iob []
FILE *	__iob [FOPEN_MAX] = { (FILE *) 1, (FILE *) 2, (FILE *) 3 }

---

Detailed Description

Standard stream interface to Nut/OS devices.

 #include <stdio.h>

In contrast to the standard, Nut/OS streams do not maintain there own buffers. Any input or output buffering is done in the device driver.

Nut/OS will not associate the standard streams stdin, stdout and stderr to a device when starting the application. Instead, freopen() can be used by the application to redirect any of these stream to any previously opened file, device or connected socket.

As an extension to the standard, many function come in an additional flavour with _P appended to their name. These functions accept specific parameters pointing into program space.

Output Call Graph

Input Call Graph

---

Define Documentation

#define EOF   (-1)

End of file.

Returned by an input or output operation when the end of a file is encountered. Some routines return this value to indicate an error.

Definition at line 101 of file stdio.h.

Referenced by _fdopen(), _fmode(), _getf(), EdLineRead(), fclose(), fflush(), fgetc(), fgets(), fopen(), fpurge(), fputc(), freopen(), gets(), NutSmtpSendEncodedLines(), puts(), puts_P(), and ungetc().

#define _IOFBF   0x00

Fully buffered.

Definition at line 105 of file stdio.h.

#define _IOLBF   0x01

Line buffered.

Definition at line 106 of file stdio.h.

#define _IONBF   0x02

Unbuffered.

Definition at line 107 of file stdio.h.

#define stdin   (__iob[0])

Standard input stream.

Examples:

caltime/caltime.c, and editconf/editconf.c.

Definition at line 123 of file stdio.h.

Referenced by EdLineOpen(), getchar(), gets(), kbhit(), main(), scanf(), and scanf_P().

#define stdout   (__iob[1])

Standard output stream.

Examples:

caltime/caltime.c, editconf/editconf.c, events/events.c, ftpd/ftpserv.c, httpd/httpserv.c, httpd_simple/httpd_simple.c, httpd_upnp/httpserv.c, icmp-udp/icmp-udp.c, inetq/inetq.c, logtime/logtime.c, pppc/pppc.c, snmpd/snmpd.c, tcps/tcps.c, threads/threads.c, and timers/timers.c.

Definition at line 124 of file stdio.h.

Referenced by EdLineOpen(), InitDebugDevice(), main(), NutInit(), NUTPANIC(), PhatDirEntryCreate(), PhatDirEntryUpdate(), PhatDirOpen(), PhatDirRead(), PhatFileClose(), PhatFileOpen(), PhatVolMount(), printf(), printf_P(), putchar(), puts(), and puts_P().

#define stderr   (__iob[2])

Standard error output stream.

Examples:

logtime/logtime.c, and snmpd/snmpd.c.

Definition at line 125 of file stdio.h.

Referenced by main(), syslog_flush(), vsyslog(), and vsyslog_P().

#define CF_LONG   0x01

Definition at line 89 of file getf.c.

Referenced by _getf().

#define CF_SUPPRESS   0x02

Definition at line 90 of file getf.c.

Referenced by _getf().

#define CF_SIGNOK   0x04

Definition at line 91 of file getf.c.

Referenced by _getf().

#define CF_NDIGITS   0x08

Definition at line 92 of file getf.c.

Referenced by _getf().

#define CF_PFXOK   0x10

Definition at line 93 of file getf.c.

Referenced by _getf().

#define CF_NZDIGITS   0x20

Definition at line 94 of file getf.c.

Referenced by _getf().

#define CF_DPTOK   0x10

Definition at line 95 of file getf.c.

Referenced by _getf().

#define CF_EXPOK   0x20

Definition at line 96 of file getf.c.

Referenced by _getf().

#define CT_CHAR   0

Definition at line 101 of file getf.c.

Referenced by _getf().

#define CT_STRING   2

Definition at line 102 of file getf.c.

Referenced by _getf().

#define CT_INT   3

Definition at line 103 of file getf.c.

Referenced by _getf().

#define CT_FLOAT   4

Definition at line 104 of file getf.c.

Referenced by _getf().

#define BUF   16

Definition at line 134 of file putf.c.

Referenced by _putf().

#define PADSIZE   16

Definition at line 138 of file putf.c.

#define ALT   0x01

Definition at line 162 of file putf.c.

Referenced by _putf().

#define LADJUST   0x04

Definition at line 163 of file putf.c.

Referenced by _putf().

#define LONGINT   0x08

Definition at line 164 of file putf.c.

Referenced by _putf().

#define ZEROPAD   0x10

Definition at line 165 of file putf.c.

Referenced by _putf().

---

Typedef Documentation

typedef struct __iobuf FILE

Stream structure type.

A pointer to this type is used for all standard I/O functions to specify a stream.

Note:

Applications should make any assumptions about the contents of this structure as it may change without further notice.

Definition at line 119 of file stdio.h.

---

Function Documentation

void clearerr

(

FILE *

stream

)

Reset error status of a stream.

Parameters:

stream

Pointer to a previously opened stream.

Note:

This function does nothing.

Definition at line 61 of file clrerr.c.

int fclose

(

FILE *

stream

)

Close a stream.

The calling thread may be suspended until all buffered output data has been written.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

0 if the stream is successfully closed, EOF otherwise.

Definition at line 76 of file fclose.c.

References __iob, _close(), EBADF, EOF, errno, FOPEN_MAX, and free().

Referenced by fcloseall(), main(), NutFtpCloseSession(), NutFtpTransferDirectoryOptions(), NutSmtpDisconnect(), service(), and Service().

Here is the call graph for this function:

void fcloseall

(

void

)

Close all open streams.

The standard streams stdin, stdout and stderr are not closed.

The calling thread may be suspended until all buffered output data has been written.

Definition at line 63 of file fcloseall.c.

References __iob, fclose(), and FOPEN_MAX.

Here is the call graph for this function:

FILE* _fdopen	(	int	fd,
		CONST char *	mode
	)

Open a stream associated with a file, device or socket descriptor.

Parameters:

fd	Descriptor of a previously opened file, device or connected socket.
mode	Specifies the access mode. "r" Read only. "w" Write only. "a" Write only at the end of file. "r+" Read and write existing file. "w+" Read and write, destroys existing file contents. "a+" Read and write, preserves existing file contents. "b" May be appended to any of the above strings to specify binary access.

Returns:

A pointer to the open stream or a null pointer to indicate an error.

Definition at line 81 of file fdopen.c.

References __iob, _fmode(), _O_TEXT, ENFILE, ENOMEM, EOF, errno, FOPEN_MAX, and malloc().

Referenced by main(), NutFtpOpenSession(), NutFtpTransferDirectoryOptions(), NutSmtpConnect(), service(), and Service().

Here is the call graph for this function:

int feof

(

FILE *

stream

)

Test if a stream reached the end of file.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

0 if the current position is not the end of the file.

Definition at line 66 of file feof.c.

References _IOEOF, and NUTASSERT.

int ferror

(

FILE *

stream

)

Test for an error on a stream.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

0 if no error occured.

Definition at line 67 of file ferror.c.

References _IOERR, and NUTASSERT.

int fflush

(

FILE *

stream

)

Flush a stream.

The calling thread may be suspended until all buffered output data has been written.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

0 if the buffer was successfully flushed, EOF if an error occured.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 71 of file fflush.c.

References _write(), EOF, and NUTASSERT.

Referenced by _flushall(), main(), NutFtpProcessPassiv(), NutFtpRespondBad(), NutFtpRespondOk(), NutFtpSendMode(), NutFtpServerSession(), NutHttpProcessRequest(), NutSmtpSendCommand(), NutSmtpSendMail(), ProcessRequests(), ShowForm(), and StreamCopy().

Here is the call graph for this function:

int fgetc

(

FILE *

stream

)

Read a character from a stream.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

Character read or EOF to indicate an error or end of file. In the latter case feof() or ferror() can be used to determine the cause of the failure.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 81 of file fgetc.c.

References _IOEOF, _IOERR, _IOUNG, _read(), EOF, and NUTASSERT.

Referenced by fgets(), getc(), getchar(), and gets().

Here is the call graph for this function:

char* fgets	(	char *	buffer,
		int	count,
		FILE *	stream
	)

Read a line from a stream.

Read at most one less than the specified number of characters from a stream or stop when a newline has been read.

Parameters:

buffer	Pointer to the buffer that receives the data including the linefeed character.
count	Maximum number of characters to read.
stream	Pointer to a previously opened stream.

Returns:

Pointer to the given buffer or NULL to indicate an error or the end of the file.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 73 of file fgets.c.

References EOF, fgetc(), and NUTASSERT.

Referenced by main(), NutFtpServerSession(), NutHttpProcessRequest(), NutSmtpReceiveResponse(), and ProcessRequests().

Here is the call graph for this function:

int _fileno

(

FILE *

stream

)

Get the file descriptor associated with a stream.

In contrast to other implementations, the standard streams stdin, stdout and stderr do not return 0, 1 and 2 resp.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

The file descriptor.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 70 of file fileno.c.

References NUTASSERT.

Referenced by InitDebugDevice(), kbhit(), main(), syslog_flush(), vfscanf(), and vfscanf_P().

void _flushall

(

void

)

Flushes all streams.

Definition at line 60 of file flushall.c.

References __iob, fflush(), and FOPEN_MAX.

Here is the call graph for this function:

int _fmode

(

CONST char *

mode

)

Definition at line 70 of file fmode.c.

References _O_APPEND, _O_BINARY, _O_CREAT, _O_RDONLY, _O_RDWR, _O_TEXT, _O_TRUNC, _O_WRONLY, EINVAL, EOF, errno, and NUTASSERT.

Referenced by _fdopen(), fopen(), and freopen().

FILE* fopen	(	CONST char *	name,
		CONST char *	mode
	)

Open a stream.

Parameters:

name	The name of a registered device, optionally followed by a colon and a filename.
mode	Specifies the access mode. "r" Read only. "w" Write only. "a" Write only at the end of file. "r+" Read and write existing file. "w+" Read and write, destroys existing file contents. "a+" Read and write, preserves existing file contents. "b" May be appended to any of the above strings to specify binary access.

Returns:

A pointer to the open stream or a null pointer to indicate an error.

Definition at line 83 of file fopen.c.

References __iob, _fmode(), _O_TEXT, _open(), ENFILE, EOF, errno, FOPEN_MAX, free(), and malloc().

Referenced by main().

Here is the call graph for this function:

int fprintf	(	FILE *	stream,
		CONST char *	fmt,
			...
	)

Print formatted data to a stream.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string containing conversion specifications.

Returns:

The number of characters written or a negative value to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 68 of file fprintf.c.

References NUTASSERT, and vfprintf().

Referenced by DhcpStateDebug(), DumpDnsHeader(), DumpDnsQuestion(), DumpDnsResource(), main(), NutArpCacheQuery(), NutArpCacheUpdate(), NutChatExpectString(), NutDhcpClient(), NutDhcpIfConfig(), NutDumpIpcp(), NutDumpIpcpOption(), NutDumpLcp(), NutDumpLcpOption(), NutDumpPap(), NutDumpPapOption(), NutDumpPpp(), NutDumpSocketList(), NutDumpTcpHeader(), NutHeapDump(), NutHttpSendHeaderTop(), NutSmtpSendMailHeader(), NutThreadCreate(), PerCiDump(), PhatDbgDirEntry(), PhatDbgFileInfo(), PhatDbgVbr(), Counter::print(), ProcessRequests(), and ShowForm().

Here is the call graph for this function:

int fprintf_P	(	FILE *	stream,
		PGM_P	fmt,
			...
	)

Print formatted data to a stream.

Similar to fprintf() except that the format string is located in program memory.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string in program space containing conversion specifications.

Returns:

The number of bytes written or a negative value to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Do not use this function with a debug device while running in interrupt context.

Definition at line 73 of file fprintf_p.c.

References vfprintf_P().

Here is the call graph for this function:

int fpurge

(

FILE *

stream

)

Purge a stream, i.e. discards the input buffer.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

0 if the buffer was successfully purged, EOF if an error occured.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 66 of file fpurge.c.

References _read(), EOF, and NUTASSERT.

Here is the call graph for this function:

int fputc	(	int	c,
		FILE *	stream
	)

Write a character to a stream.

Parameters:

c	Character to write.
stream	Pointer to a previously opened stream.

Returns:

The character written or EOF to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 69 of file fputc.c.

References _write(), EOF, and NUTASSERT.

Referenced by DumpDnsResource(), NutArpCacheUpdate(), NutChatExpectString(), NutDumpHeap(), NutDumpPapOption(), NutDumpThreadList(), NutFtpTransferDirectoryOptions(), NutSmtpSendEncodedLines(), PerCiDump(), PhatDbgAttrList(), PhatDbgDirEntry(), putc(), putchar(), puts(), puts_P(), vsyslog(), and vsyslog_P().

Here is the call graph for this function:

int fputs	(	CONST char *	string,
		FILE *	stream
	)

Write a string to a stream.

Parameters:

stream	Pointer to a previously opened stream.
string	String to write.

Returns:

A non-negative value if successful or EOF to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 70 of file fputs.c.

References _write(), NUTASSERT, and strlen().

Referenced by IpcpClose(), IpcpLowerDown(), IpcpLowerUp(), IpcpOpen(), LcpClose(), LcpLowerDown(), LcpLowerUp(), LcpOpen(), main(), NutDumpIpcp(), NutDumpIpcpOption(), NutDumpLcp(), NutDumpLcpOption(), NutDumpPap(), NutDumpPapOption(), NutDumpPpp(), NutDumpSocketList(), NutDumpSockState(), NutDumpTcpHeader(), NutDumpThreadList(), NutDumpThreadQueue(), NutFtpTransferDirectoryOptions(), NutPppInput(), NutPppOutput(), NutSmtpSendCommand(), NutSmtpSendEncodedLines(), NutSmtpSendMail(), PerCiDump(), PhatDbgDirEntry(), ProcessRequests(), puts(), vsyslog(), and vsyslog_P().

Here is the call graph for this function:

int fputs_P	(	PGM_P	string,
		FILE *	stream
	)

Write a string from progam memory to a stream.

Similar to fputs() except that the string is located in program space.

Parameters:

stream	Pointer to a previously opened stream.
string	String in program memory to write.

Returns:

A non-negative value if successful or EOF to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 73 of file fputs_p.c.

References _write_P(), NUTASSERT, and strlen_P.

Here is the call graph for this function:

size_t fread	(	void *	buffer,
		size_t	size,
		size_t	count,
		FILE *	stream
	)

Read data from a stream.

Parameters:

buffer	Pointer to the buffer that receives the data.
size	Item size in bytes.
count	Maximum number of items to read.
stream	Pointer to a previously opened stream.

Returns:

The number of full items read, which may be less then the specified number.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 75 of file fread.c.

References _IOEOF, _IOERR, _IOUNG, _read(), and NUTASSERT.

Referenced by main(), NutHttpProcessPostQuery(), and StreamCopy().

Here is the call graph for this function:

FILE* freopen	(	CONST char *	name,
		CONST char *	mode,
		FILE *	stream
	)

Reassign a stream.

Parameters:

name	The name of a registered device, optionally followed by a colon and a filename.
mode	Specifies the access mode. "r" Read only. "w" Write only. "a" Write only at the end of file. "r+" Read and write existing file. "w+" Read and write, destroys existing file contents. "a+" Read and write, preserves existing file contents. "b" May be appended to any of the above strings to specify binary access.
stream	Pointer to a previously opened stream.

Returns:

A pointer to the open stream or a null pointer to indicate an error.

Definition at line 93 of file freopen.c.

References __iob, _fmode(), _O_TEXT, _open(), EBADF, EOF, errno, FOPEN_MAX, free(), and malloc().

Referenced by InitDebugDevice(), and main().

Here is the call graph for this function:

int fscanf	(	FILE *	stream,
		CONST char *	fmt,
			...
	)

Read formatted data from a stream.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 69 of file fscanf.c.

References NUTASSERT, and vfscanf().

Here is the call graph for this function:

int fscanf_P	(	FILE *	stream,
		PGM_P	fmt,
			...
	)

Read formatted data from a stream.

Similar to fscanf() except that the format string is expected in program space.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string in program space containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 68 of file fscanf_p.c.

References vfscanf_P().

Here is the call graph for this function:

int fseek	(	FILE *	stream,
		long	offset,
		int	origin
	)

Move read/write position of a stream.

Parameters:

stream	Pointer to a previously opened stream.
offset	Number of bytes from initial position.
origin	Initial position to seek from.

Returns:

0 if no error occured. -1 on error. Errno is set

Definition at line 70 of file fseek.c.

References _seek(), and NUTASSERT.

Here is the call graph for this function:

long ftell

(

FILE *

stream

)

Return the read/write position of a stream.

Parameters:

stream

Pointer to a previously opened stream.

Returns:

The current position.

Definition at line 68 of file ftell.c.

References _tell(), and NUTASSERT.

Here is the call graph for this function:

size_t fwrite	(	CONST void *	data,
		size_t	size,
		size_t	count,
		FILE *	stream
	)

Write data to a stream.

Parameters:

data	Pointer to items to be written.
size	Item size in bytes.
count	Number of items to write.
stream	Pointer to a previously opened stream.

Returns:

The number of items written, which may be less than the specified number.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 79 of file fwrite.c.

References _write(), and NUTASSERT.

Referenced by NutHttpProcessAsp(), and StreamCopy().

Here is the call graph for this function:

size_t fwrite_P	(	PGM_P	data,
		size_t	size,
		size_t	count,
		FILE *	stream
	)

Write data from program space to a stream.

Similar to fwrite() except that the data is located in program memory.

Parameters:

data	Pointer to items in program space to be written.
size	Item size in bytes.
count	Number of items to write.
stream	Pointer to a previously opened stream.

Returns:

The number of items written, which may be less than the specified number.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 73 of file fwrite_p.c.

References _write_P(), and NUTASSERT.

Here is the call graph for this function:

int getc

(

FILE *

stream

)

Read a character from a stream.

Same as fgetc().

Parameters:

stream

Pointer to a previously opened stream.

Returns:

Character read or EOF to indicate an error or end of file.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 66 of file getc.c.

References fgetc().

Here is the call graph for this function:

int getchar

(

void

)

Read a character from a standard input.

Returns:

Character read or EOF to indicate an error or end of file.

Definition at line 56 of file getchar.c.

References fgetc(), and stdin.

Referenced by main().

Here is the call graph for this function:

int _getf	(	int	_getbint, void *, size_t,
		int	fd,
		CONST char *	fmt,
		va_list	ap
	)

Read formatted data using a given input function.

Parameters:

_getb	Input function for reading data.
fd	Descriptor of a previously opened file, device or connected socket.
fmt	Format string containing coversion specifications.
ap	List of pointer arguments.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 119 of file getf.c.

References CF_DPTOK, CF_EXPOK, CF_LONG, CF_NDIGITS, CF_NZDIGITS, CF_PFXOK, CF_SIGNOK, CF_SUPPRESS, CT_CHAR, CT_FLOAT, CT_INT, CT_STRING, EOF, and strtol().

Referenced by vfscanf(), vfscanf_P(), vsscanf(), and vsscanf_P().

Here is the call graph for this function:

char* gets

(

char *

buffer

)

Get a line from the standard input stream.

Read characters from a stream until a newline has been read.

Parameters:

buffer

Pointer to the buffer that receives the line excluding the linefeed character.

Returns:

The given argument on success, 0 otherwise.

Warning:

This function is potentially unsafe, because it may write pass the end of the buffer.

Definition at line 69 of file gets.c.

References EOF, fgetc(), NUTASSERT, and stdin.

Here is the call graph for this function:

int printf	(	CONST char *	fmt,
			...
	)

Print formatted data to the standard output stream.

Parameters:

fmt	Format string containing conversion specifications.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 64 of file printf.c.

References NUTASSERT, stdout, and vfprintf().

Here is the call graph for this function:

int printf_P	(	PGM_P	fmt,
			...
	)

Print formatted output to the standard output stream.

Similar to printf() except that the format string is located in program memory.

Parameters:

fmt	Format string in program space containing conversion specifications.

Returns:

The number of characters written or a negative value to indicate an error.

Warning:

Do not use this function with a debug device while running in interrupt context.

Definition at line 70 of file printf_p.c.

References stdout, and vfprintf_P().

Referenced by NutFtpDataConnect(), and NutFtpServerSession().

Here is the call graph for this function:

int putc	(	int	c,
		FILE *	stream
	)

Write a character to a stream.

Same as fputc().

Parameters:

c	Character to write.
stream	Pointer to a previously opened stream.

Returns:

The character written or EOF to indicate an error.

Warning:

The function will not check, if the stream pointer points to a valid stream.

Definition at line 67 of file putc.c.

References fputc().

Here is the call graph for this function:

int putchar

(

int

c

)

Write a character to standard output.

Parameters:

c	Character to write.

Returns:

The character written or EOF to indicate an error.

Definition at line 61 of file putchar.c.

References fputc(), and stdout.

Referenced by ARM_COMMON_Handler_crash(), main(), ptrace_dump_regs(), Thread1(), Thread2(), X12RtcReadRegs(), and X12RtcWrite().

Here is the call graph for this function:

int _putf	(	int	_putbint, CONST void *, size_t,
		int	fd,
		CONST char *	fmt,
		va_list	ap
	)

Write formatted data using a given output function.

Parameters:

_putb	Output function for writing data.
fd	Descriptor of a previously opened file, device or connected socket.
fmt	Format string containing conversion specifications.
ap	List of arguments.

Definition at line 178 of file putf.c.

References ALT, BUF, free(), LADJUST, LONGINT, malloc(), memchr(), PGM_P, strcpy(), strcpy_P, strlen(), strlen_P, and ZEROPAD.

Referenced by vfprintf(), vfprintf_P(), vsprintf(), and vsprintf_P().

Here is the call graph for this function:

int puts

(

CONST char *

string

)

Write a string to stdout.

Parameters:

string

String to write.

Returns:

A non-negative value or EOF to indicate an error.

Definition at line 58 of file puts.c.

References EOF, fputc(), fputs(), and stdout.

Here is the call graph for this function:

int puts_P

(

PGM_P

string

)

Write a string from program memory to stdout.

Similar to puts() except that the string is located in program memory.

Parameters:

string

String in program memory to write.

Returns:

A non-negative value or EOF to indicate an error.

Definition at line 61 of file puts_p.c.

References EOF, fputc(), fputs_P, and stdout.

Referenced by NutFtpDataConnect(), and NutFtpTransferFile().

Here is the call graph for this function:

int scanf	(	CONST char *	fmt,
			...
	)

Read formatted data from the standard input stream.

Parameters:

fmt	Format string containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, ff an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 65 of file scanf.c.

References NUTASSERT, stdin, and vfscanf().

Here is the call graph for this function:

int scanf_P	(	PGM_P	fmt,
			...
	)

Read formatted data from the standard input stream.

Similar to scanf() except that the format string is located in program space.

Parameters:

fmt	Format string containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, ff an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 63 of file scanf_p.c.

References stdin, and vfscanf_P().

Here is the call graph for this function:

int sprintf	(	char *	buffer,
		CONST char *	fmt,
			...
	)

Write formatted data to a string.

Parameters:

buffer	Pointer to a buffer that receives the output string.
fmt	Format string containing conversion specifications.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 65 of file sprintf.c.

References NUTASSERT, and vsprintf().

Here is the call graph for this function:

int sprintf_P	(	char *	buffer,
		PGM_P	fmt,
			...
	)

Write formatted data to a string.

Similar to sprintf() except that the format string is located in program memory.

Parameters:

buffer	Pointer to a buffer that receives the output string.
fmt	Format string in program space containing conversion specifications.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 71 of file sprintf_p.c.

References vsprintf_P().

Here is the call graph for this function:

int sscanf	(	CONST char *	string,
		CONST char *	fmt,
			...
	)

Read formatted data from a string.

Parameters:

string	Pointer to the string that contains the data.
fmt	Format string containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 61 of file sscanf.c.

References vsscanf().

Here is the call graph for this function:

int sscanf_P	(	CONST char *	string,
		CONST char *	fmt,
			...
	)

Read formatted data from a string.

Similar to sscanf() except that the format string is located in program space.

Parameters:

string	Pointer to the string that contains the data.
fmt	Format string in program space containing conversion specifications.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 68 of file sscanf_p.c.

References PGM_P, and vsscanf_P().

Here is the call graph for this function:

int ungetc	(	int	c,
		FILE *	stream
	)

Push a character back onto a stream.

Parameters:

c	Character to push back.
stream	Pointer to a previously opened stream.

Warning:

Only a single character can be pushed back. Any previously pushed and not yet read character will be lost.

Definition at line 65 of file ungetc.c.

References _IOUNG, EOF, and NUTASSERT.

int vfprintf	(	FILE *	stream,
		CONST char *	fmt,
		va_list	ap
	)

Write argument list to a stream using a given format.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string containing conversion specifications.
ap	List of arguments.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 68 of file vfprintf.c.

References _putf(), _write(), and NUTASSERT.

Referenced by fprintf(), NUTPANIC(), NutSmtpSendCommand(), printf(), and vsyslog().

Here is the call graph for this function:

int vfprintf_P	(	FILE *	stream,
		PGM_P	fmt,
		va_list	ap
	)

Write argument list to a stream using a given format.

Similar to vfprintf() except that the format string is located in program memory.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string in program space containing conversion specifications.
ap	List of arguments.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 74 of file vfprintf_p.c.

References _putf(), _write(), memcpy_P, NUTASSERT, NutHeapAlloc, NutHeapFree, and strlen_P.

Referenced by fprintf_P(), printf_P(), and vsyslog_P().

Here is the call graph for this function:

int vfscanf	(	FILE *	stream,
		CONST char *	fmt,
		va_list	ap
	)

Read formatted data from a stream.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string containing conversion specifications.
ap	List of pointer arguments.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 66 of file vfscanf.c.

References _fileno(), _getf(), and _read().

Referenced by fscanf(), and scanf().

Here is the call graph for this function:

int vfscanf_P	(	FILE *	stream,
		PGM_P	fmt,
		va_list	ap
	)

Read formatted data from a stream.

Similar to vfscanf() except that the format string is located in program space.

Parameters:

stream	Pointer to a previously opened stream.
fmt	Format string in program space containing conversion specifications.
ap	List of pointer arguments.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 73 of file vfscanf_p.c.

References _fileno(), _getf(), _read(), memcpy_P, NutHeapAlloc, NutHeapFree, and strlen_P.

Referenced by fscanf_P(), and scanf_P().

Here is the call graph for this function:

int vsprintf	(	char *	buffer,
		CONST char *	fmt,
		va_list	ap
	)

Write argument list to a string using a given format.

Parameters:

buffer	Pointer to a buffer that receives the output string.
fmt	Format string containing conversion specifications.
ap	List of arguments.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 83 of file vsprintf.c.

References _putf().

Referenced by PerCiWriteVarList(), sprintf(), and vsyslog().

Here is the call graph for this function:

int vsprintf_P	(	char *	buffer,
		PGM_P	fmt,
		va_list	ap
	)

Write argument list to a string using a given format.

Similar to vsprintf() except that the format string is located in program memory.

Parameters:

buffer	Pointer to a buffer that receives the output string.
fmt	Format string in program space containing conversion specifications.
ap	List of arguments.

Returns:

The number of characters written or a negative value to indicate an error.

Definition at line 85 of file vsprintf_p.c.

References _putf(), memcpy_P, NutHeapAlloc, NutHeapFree, and strlen_P.

Referenced by sprintf_P(), and vsyslog_P().

Here is the call graph for this function:

int vsscanf	(	CONST char *	string,
		CONST char *	fmt,
		va_list	ap
	)

Read formatted data from a string.

Parameters:

string	Pointer to a string that contains the data.
fmt	Format string containing conversion specifications.
ap	List of pointer arguments.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 95 of file vsscanf.c.

References _getf(), and CONST.

Referenced by sscanf().

Here is the call graph for this function:

int vsscanf_P	(	CONST char *	string,
		PGM_P	fmt,
		va_list	ap
	)

Read formatted data from a string.

Similar to vsscanf() except that the format string is located in program space.

Parameters:

string	Pointer to a string that contains the data.
fmt	Format string in program space containing conversion specifications.
ap	List of pointer arguments.

Returns:

The number of fields successfully converted and assigned. The return value is EOF, if an error occurs or if the end of the stream is reached before the first conversion.

Definition at line 97 of file vsscanf_p.c.

References _getf(), CONST, memcpy_P, NutHeapAlloc, NutHeapFree, and strlen_P.

Referenced by sscanf_P().

Here is the call graph for this function:

---

Variable Documentation

FILE* __iob[]

Definition at line 63 of file fopen.c.

Referenced by _fdopen(), _flushall(), fclose(), fcloseall(), fopen(), and freopen().

FILE* __iob[FOPEN_MAX] = { (FILE *) 1, (FILE *) 2, (FILE *) 3 }

Definition at line 63 of file fopen.c.

Referenced by _fdopen(), _flushall(), fclose(), fcloseall(), fopen(), and freopen().
