at91_wdt.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Watch Dog Control Register
#define	WDT_CR_OFF   0x00000000
	Watchdog control register offset.
#define	WDT_CR   (WDT_BASE + WDT_CR_OFF)
	Watchdog control register address.
#define	WDT_WDRSTT   0x00000001
	Watchdog restart.
#define	WDT_KEY   0xA5000000
	Watchdog password.
Watch Dog Mode Register
#define	WDT_MR_OFF   0x00000004
	Mode register offset.
#define	WDT_MR   (WDT_BASE + WDT_MR_OFF)
	Mode register address.
#define	WDT_WDV   0x00000FFF
	Counter value mask.
#define	WDT_WDV_LSB   0
	Counter value LSB.
#define	WDT_WDFIEN   0x00001000
	Fault interrupt enable.
#define	WDT_WDRSTEN   0x00002000
	Reset enable.
#define	WDT_WDRPROC   0x00004000
	Eset processor enable.
#define	WDT_WDDIS   0x00008000
	Watchdog disable.
#define	WDT_WDD   0x0FFF0000
	Delta value mask.
#define	WDT_WDD_LSB   16
	Delta value LSB.
#define	WDT_WDDBGHLT   0x10000000
	Watchdog debug halt.
#define	WDT_WDIDLEHLT   0x20000000
	Watchdog idle halt.
Watch Dog Status Register
#define	WDT_SR_OFF   0x00000008
	Status register offset.
#define	WDT_SR   (WDT_BASE + WDT_SR_OFF)
	Status register address.
#define	WDT_WDUNF   0x00000001
	Watchdog underflow.
#define	WDT_WDERR   0x00000002
	Watchdog error.
