Go to the source code of this file.
SSC Control Register | |
#define | SSC_CR_OFF 0x00000000 |
Control register offset. | |
#define | SSC_CR (SSC_BASE + SSC_CR_OFF) |
Control register address. | |
#define | SSC_RXEN 0x00000001 |
Receive enable. | |
#define | SSC_RXDIS 0x00000002 |
Receive disable. | |
#define | SSC_TXEN 0x00000100 |
Transmit enable. | |
#define | SSC_TXDIS 0x00000200 |
Transmit disable. | |
#define | SSC_SWRST 0x00008000 |
Software reset. | |
SSC Clock Mode Register | |
#define | SSC_CMR_OFF 0x00000004 |
Clock mode register offset. | |
#define | SSC_CMR (SSC_BASE + SSC_CMR_OFF) |
Clock mode register address. | |
#define | SSC_DIV_LSB 0 |
Least significant bit of clock divider. | |
#define | SSC_DIV 0x00000FFF |
Clock divider. | |
SSC Receive/Transmit Clock Mode Register | |
#define | SSC_RCMR_OFF 0x00000010 |
Receive clock mode register offset. | |
#define | SSC_RCMR (SSC_BASE + SSC_RCMR_OFF) |
Receive clock mode register address. | |
#define | SSC_TCMR_OFF 0x00000018 |
Transmit clock mode register offset. | |
#define | SSC_TCMR (SSC_BASE + SSC_TCMR_OFF) |
Transmit clock mode register address. | |
#define | SSC_CKS 0x00000003 |
Receive clock selection. | |
#define | SSC_CKS_DIV 0x00000000 |
Divided clock. | |
#define | SSC_CKS_CLK 0x00000001 |
RK/TK clock signal. | |
#define | SSC_CKS_PIN 0x00000002 |
TK/RK pin. | |
#define | SSC_CKO 0x0000001C |
Receive clock output mode selection. | |
#define | SSC_CKO_NONE 0x00000000 |
None. | |
#define | SSC_CKO_CONT 0x00000004 |
Continous receive clock. | |
#define | SSC_CKO_TRAN 0x00000008 |
Receive clock only during data transfers. | |
#define | SSC_CKI 0x00000020 |
Receive clock inversion. | |
#define | SSC_CKG 0x000000C0 |
Receive clock gating selection. | |
#define | SSC_CKG_NONE 0x00000000 |
None, continous clock. | |
#define | SSC_CKG_RFL 0x00000040 |
Continous receive clock. | |
#define | SSC_CKG_RFH 0x00000080 |
Receive clock only during data transfers. | |
#define | SSC_START 0x00000F00 |
Receive start selection. | |
#define | SSC_START_CONT 0x00000000 |
Receive start as soon as enabled. | |
#define | SSC_START_TX 0x00000100 |
Receive start on transmit start. | |
#define | SSC_START_LOW_RF 0x00000200 |
Receive start on low level RF. | |
#define | SSC_START_HIGH_RF 0x00000300 |
Receive start on high level RF. | |
#define | SSC_START_FALL_RF 0x00000400 |
Receive start on falling edge RF. | |
#define | SSC_START_RISE_RF 0x00000500 |
Receive start on rising edge RF. | |
#define | SSC_START_LEVEL_RF 0x00000600 |
Receive start on any RF level change. | |
#define | SSC_START_EDGE_RF 0x00000700 |
Receive start on any RF edge. | |
#define | SSC_START_COMP0 0x00000800 |
Receive on compare 0. | |
#define | SSC_STOP 0x00001000 |
Receive stop selection. | |
#define | SSC_STTDLY 0x00FF0000 |
Receive start delay. | |
#define | SSC_STTDLY_LSB 16 |
Least significant bit of receive start delay. | |
#define | SSC_PERIOD 0xFF000000 |
Receive period divider selection. | |
#define | SSC_PERIOD_LSB 24 |
Least significant bit of receive period divider selection. | |
SSC Receive/Transmit Frame Mode Registers | |
#define | SSC_RFMR_OFF 0x00000014 |
Receive frame mode register offset. | |
#define | SSC_RFMR (SSC_BASE + SSC_RFMR_OFF) |
Receive frame mode register address. | |
#define | SSC_TFMR_OFF 0x0000001C |
Transmit frame mode register offset. | |
#define | SSC_TFMR (SSC_BASE + SSC_TFMR_OFF) |
Transmit frame mode register address. | |
#define | SSC_DATLEN 0x0000001F |
Data length. | |
#define | SSC_DATLEN_LSB 0 |
Least significant bit of data length. | |
#define | SSC_LOOP 0x00000020 |
Receiver loop mode. | |
#define | SSC_DATDEF 0x00000020 |
Transmit default value. | |
#define | SSC_MSBF 0x00000080 |
Most significant bit first. | |
#define | SSC_DATNB 0x00000F00 |
Data number per frame. | |
#define | SSC_DATNB_LSB 8 |
Least significant bit of data number per frame. | |
#define | SSC_FSLEN 0x000F0000 |
Receive frame sync. length. | |
#define | SSC_FSLEN_LSB 16 |
Least significant bit of receive frame sync. length. | |
#define | SSC_FSOS 0x00700000 |
Receive frame sync. output selection. | |
#define | SSC_FSOS_NONE 0x00000000 |
No frame sync. Line set to input. | |
#define | SSC_FSOS_NEGATIVE 0x00100000 |
Negative pulse. | |
#define | SSC_FSOS_POSITIVE 0x00200000 |
Positive pulse. | |
#define | SSC_FSOS_LOW 0x00300000 |
Low during transfer. | |
#define | SSC_FSOS_HIGH 0x00400000 |
High during transfer. | |
#define | SSC_FSOS_TOGGLE 0x00500000 |
Toggling at each start. | |
#define | SSC_FSDEN 0x00800000 |
Frame sync. data enable. | |
#define | SSC_FSEDGE 0x01000000 |
Frame sync. edge detection. | |
SSC Receive Holding Register | |
#define | SSC_RHR_OFF 0x00000020 |
Receive holding register offset. | |
#define | SSC_RHR (SSC_BASE + SSC_RHR_OFF) |
Receive holding register address. | |
SSC Transmit Holding Register | |
#define | SSC_THR_OFF 0x00000024 |
Transmit holding register offset. | |
#define | SSC_THR (SSC_BASE + SSC_THR_OFF) |
Transmit holding register address. | |
SSC Receive Sync. Holding Register | |
#define | SSC_RSHR_OFF 0x00000030 |
Receive sync. holding register offset. | |
#define | SSC_RSHR (SSC_BASE + SSC_RSHR_OFF) |
Receive sync. holding register address. | |
SSC Transmit Sync. Holding Register | |
#define | SSC_TSHR_OFF 0x00000034 |
Transmit sync. holding register offset. | |
#define | SSC_TSHR (SSC_BASE + SSC_TSHR_OFF) |
Transmit sync. holding register address. | |
SSC Receive Compare 0 Register | |
#define | SSC_RC0R_OFF 0x00000038 |
Receive compare 0 register offset. | |
#define | SSC_RC0R (SSC_BASE + SSC_RC0R_OFF) |
Receive compare 0 register address. | |
SSC Receive Compare 1 Register | |
#define | SSC_RC1R_OFF 0x0000003C |
Receive compare 1 register offset. | |
#define | SSC_RC1R (SSC_BASE + SSC_RC1R_OFF) |
Receive compare 1 register address. | |
SSC Status Register | |
#define | SSC_SR_OFF 0x00000040 |
Status register offset. | |
#define | SSC_SR (SSC_BASE + SSC_SR_OFF) |
Status register address. | |
#define | SSC_TXRDY 0x00000001 |
Transmit ready. | |
#define | SSC_TXEMPTY 0x00000002 |
Transmit empty. | |
#define | SSC_ENDTX 0x00000004 |
End of transmission. | |
#define | SSC_TXBUFE 0x00000008 |
Transmit buffer empty. | |
#define | SSC_RXRDY 0x00000010 |
Receive ready. | |
#define | SSC_OVRUN 0x00000020 |
Receive overrun. | |
#define | SSC_ENDRX 0x00000040 |
End of receiption. | |
#define | SSC_RXBUFF 0x00000080 |
Receive buffer full. | |
#define | SSC_CP0 0x00000100 |
Compare 0. | |
#define | SSC_CP1 0x00000200 |
Compare 1. | |
#define | SSC_TXSYN 0x00000400 |
Transmit sync. | |
#define | SSC_RXSYN 0x00000800 |
Receive sync. | |
#define | SSC_TXENA 0x00010000 |
Transmit enable. | |
#define | SSC_RXENA 0x00020000 |
Receive enable. | |
SSC Interrupt Enable Register | |
#define | SSC_IER_OFF 0x00000044 |
Interrupt enable register offset. | |
#define | SSC_IER (SSC_BASE + SSC_IER_OFF) |
Interrupt enable register address. | |
SSC Interrupt Disable Register | |
#define | SSC_IDR_OFF 0x00000048 |
Interrupt disable register offset. | |
#define | SSC_IDR (SSC_BASE + SSC_IDR_OFF) |
Interrupt disable register address. | |
SSC Interrupt Mask Register | |
#define | SSC_IMR_OFF 0x0000004C |
Interrupt mask register offset. | |
#define | SSC_IMR (SSC_BASE + SSC_IMR_OFF) |
Interrupt mask register address. |
