System Clock Enable, Disable and Status Register | |
#define | PMC_SCER_OFF 0x00000000 |
System clock enable register offset. | |
#define | PMC_SCER (PMC_BASE + PMC_SCER_OFF) |
System clock enable register address. | |
#define | PMC_SCDR_OFF 0x00000004 |
System clock disable register offset. | |
#define | PMC_SCDR (PMC_BASE + PMC_SCDR_OFF) |
System clock disable register address. | |
#define | PMC_SCSR_OFF 0x00000008 |
System clock status register offset. | |
#define | PMC_SCSR (PMC_BASE + PMC_SCSR_OFF) |
System clock status register address. | |
#define | PMC_PCK 0x00000001 |
Processor clock. | |
#define | PMC_UHP 0x00000040 |
USB host port clock. | |
#define | PMC_UDP 0x00000080 |
USB device port clock. | |
#define | PMC_PCK0 0x00000100 |
Programmable clock 0 output. | |
#define | PMC_PCK1 0x00000200 |
Programmable clock 1 output. | |
#define | PMC_PCK2 0x00000400 |
Programmable clock 2 output. | |
#define | PMC_PCK3 0x00000800 |
Programmable clock 3 output. | |
Peripheral Clock Enable, Disable and Status Register | |
#define | PMC_PCER_OFF 0x00000010 |
Peripheral clock enable register offset. | |
#define | PMC_PCER (PMC_BASE + PMC_PCER_OFF) |
Peripheral clock enable register address. | |
#define | PMC_PCDR_OFF 0x00000014 |
Peripheral clock disable register offset. | |
#define | PMC_PCDR (PMC_BASE + PMC_PCDR_OFF) |
Peripheral clock disable register address. | |
#define | PMC_PCSR_OFF 0x00000018 |
Peripheral clock status register offset. | |
#define | PMC_PCSR (PMC_BASE + PMC_PCSR_OFF) |
Peripheral clock status register address. | |
Clock Generator Main Oscillator Register | |
#define | CKGR_MOR_OFF 0x00000020 |
Main oscillator register offset. | |
#define | CKGR_MOR (PMC_BASE + CKGR_MOR_OFF) |
Main oscillator register address. | |
#define | CKGR_MOSCEN 0x00000001 |
Main oscillator enable. | |
#define | CKGR_OSCBYPASS 0x00000002 |
Main oscillator bypass. | |
#define | CKGR_OSCOUNT 0x0000FF00 |
Main oscillator start-up time mask. | |
#define | CKGR_OSCOUNT_LSB 8 |
Main oscillator start-up time LSB. | |
Clock Generator Main Clock Frequency Register | |
#define | CKGR_MCFR_OFF 0x00000024 |
Main clock frequency register offset. | |
#define | CKGR_MCFR (PMC_BASE + CKGR_MCFR_OFF) |
Main clock frequency register address. | |
#define | CKGR_MAINF 0x0000FFFF |
Main clock frequency mask mask. | |
#define | CKGR_MAINF_OFF 0 |
Main clock frequency mask LSB. | |
#define | CKGR_MAINRDY 0x00010000 |
Main clock ready. | |
PLL Registers | |
#define | CKGR_PLLR_OFF 0x0000002C |
Clock generator PLL register offset. | |
#define | CKGR_PLLR (PMC_BASE + CKGR_PLLR_OFF) |
Clock generator PLL register address. | |
#define | CKGR_DIV 0x000000FF |
Divider. | |
#define | CKGR_DIV_LSB 0 |
Least significant bit of the divider. | |
#define | CKGR_DIV_0 0x00000000 |
Divider output is 0. | |
#define | CKGR_DIV_BYPASS 0x00000001 |
Divider is bypassed. | |
#define | CKGR_PLLCOUNT 0x00003F00 |
PLL counter mask. | |
#define | CKGR_PLLCOUNT_LSB 8 |
PLL counter LSB. | |
#define | CKGR_OUT 0x0000C000 |
PLL output frequency range. | |
#define | CKGR_OUT_0 0x00000000 |
Please refer to the PLL datasheet. | |
#define | CKGR_OUT_1 0x00004000 |
Please refer to the PLL datasheet. | |
#define | CKGR_OUT_2 0x00008000 |
Please refer to the PLL datasheet. | |
#define | CKGR_OUT_3 0x0000C000 |
Please refer to the PLL datasheet. | |
#define | CKGR_MUL 0x07FF0000 |
PLL multiplier. | |
#define | CKGR_MUL_LSB 16 |
Least significant bit of the PLL multiplier. | |
#define | CKGR_USBDIV 0x30000000 |
Divider for USB clocks. | |
#define | CKGR_USBDIV_1 0x00000000 |
Divider output is PLL clock output. | |
#define | CKGR_USBDIV_2 0x10000000 |
Divider output is PLL clock output divided by 2. | |
#define | CKGR_USBDIV_4 0x20000000 |
Divider output is PLL clock output divided by 4. | |
Master Clock Register | |
#define | PMC_MCKR_OFF 0x00000030 |
Master clock register offset. | |
#define | PMC_MCKR (PMC_BASE + PMC_MCKR_OFF) |
Master clock register address. | |
#define | PMC_ACKR_OFF 0x00000034 |
Application clock register offset. | |
#define | PMC_ACKR (PMC_BASE + PMC_ACKR_OFF) |
Application clock register address. | |
#define | PMC_PCKR0_OFF 0x00000040 |
Programmable clock 0 register offset. | |
#define | PMC_PCKR0 (PMC_BASE + PMC_PCKR0_OFF) |
Programmable clock 0 register address. | |
#define | PMC_PCKR1_OFF 0x00000044 |
Programmable clock 1 register offset. | |
#define | PMC_PCKR1 (PMC_BASE + PMC_PCKR1_OFF) |
Programmable clock 1 register address. | |
#define | PMC_PCKR2_OFF 0x00000048 |
Programmable clock 2 register offset. | |
#define | PMC_PCKR2 (PMC_BASE + PMC_PCKR2_OFF) |
Programmable clock 2 register address. | |
#define | PMC_PCKR3_OFF 0x0000004C |
Programmable clock 3 register offset. | |
#define | PMC_PCKR3 (PMC_BASE + PMC_PCKR3_OFF) |
Programmable clock 3 register address. | |
#define | PMC_CSS 0x00000003 |
Clock selection mask. | |
#define | PMC_CSS_SLOW_CLK 0x00000000 |
Slow clock selected. | |
#define | PMC_CSS_MAIN_CLK 0x00000001 |
Main clock selected. | |
#define | PMC_CSS_PLL_CLK 0x00000003 |
PLL clock selected. | |
#define | PMC_PRES 0x0000001C |
Clock prescaler mask. | |
#define | PMC_PRES_LSB 2 |
Clock prescaler LSB. | |
#define | PMC_PRES_CLK 0x00000000 |
Selected clock, not divided. | |
#define | PMC_PRES_CLK_2 0x00000004 |
Selected clock divided by 2. | |
#define | PMC_PRES_CLK_4 0x00000008 |
Selected clock divided by 4. | |
#define | PMC_PRES_CLK_8 0x0000000C |
Selected clock divided by 8. | |
#define | PMC_PRES_CLK_16 0x00000010 |
Selected clock divided by 16. | |
#define | PMC_PRES_CLK_32 0x00000014 |
Selected clock divided by 32. | |
#define | PMC_PRES_CLK_64 0x00000018 |
Selected clock divided by 64. | |
Power Management Status and Interrupt Registers | |
#define | PMC_IER_OFF 0x00000060 |
Interrupt enable register offset. | |
#define | PMC_IER (PMC_BASE + PMC_IER_OFF) |
Interrupt enable register address. | |
#define | PMC_IDR_OFF 0x00000064 |
Interrupt disable register offset. | |
#define | PMC_IDR (PMC_BASE + PMC_IDR_OFF) |
Interrupt disable register address. | |
#define | PMC_SR_OFF 0x00000068 |
Status register offset. | |
#define | PMC_SR (PMC_BASE + PMC_SR_OFF) |
Status register address. | |
#define | PMC_IMR_OFF 0x0000006C |
Interrupt mask register offset. | |
#define | PMC_IMR (PMC_BASE + PMC_IMR_OFF) |
Interrupt mask register address. | |
#define | PMC_MOSCS 0x00000001 |
Main oscillator. | |
#define | PMC_LOCK 0x00000004 |
PLL lock. | |
#define | PMC_MCKRDY 0x00000008 |
Master clock ready. | |
#define | PMC_OSC_SEL 0x00000080 |
32 kHz external slow clock. | |
#define | PMC_PCKRDY0 0x00000100 |
Programmable clock 0 ready. | |
#define | PMC_PCKRDY1 0x00000200 |
Programmable clock 1 ready. | |
#define | PMC_PCKRDY2 0x00000400 |
Programmable clock 2 ready. | |
#define | PMC_PCKRDY3 0x00000800 |
Programmable clock 3 ready. | |
Power Management Charge Pump Current Register | |
#define | PMC_PLLICPR_OFF 0x00000080 |
Charge pump current register offset. | |
#define | PMC_PLLICPR (PMC_BASE + PMC_PLLICPR_OFF) |
Charge pump current register address. | |
#define | PMC_PLLICPR_ICPPLLA 0x00000001 |
PLL A charge pump current. | |
#define | PMC_PLLICPR_ICPPLLB 0x00000100 |
PLL B charge pump current. |
