Routines for Atmel AT45 serial dataflash memory chips. More...

#include <cfg/os.h>
#include <cfg/memory.h>
#include <sys/timer.h>
#include <string.h>
#include <stdlib.h>
#include <dev/at91_spi.h>
#include <dev/at45db.h>

Include dependency graph for at45db.c:

Go to the source code of this file.

Data Structures
struct	_AT45_DEVTAB
	Known device type entry. More...
struct	_AT45DB_DCB
	Active device entry. More...
Defines
#define	MAX_AT45_DEVICES 1
#define	MAX_AT45_CMDLEN 8
#define	AT45_CONF_DFSPI SPI0_BASE
#define	AT45_CONF_DFPCS 1
#define	AT45_ERASE_WAIT 3000
#define	AT45_CHIP_ERASE_WAIT 50000
#define	AT45_WRITE_POLLS 1000
#define	AT45DB_AT91
Typedefs
typedef struct _AT45_DEVTAB	AT45_DEVTAB
	Known device type entry.
typedef struct _AT45DB_DCB	AT45DB_DCB
	Active device entry.
Functions
int	At45dbSendCmd (int dd, uint8_t op, uint32_t parm, int len, CONST void tdata, void rdata, int datalen)
	Send DataFlash command.
uint8_t	At45dbGetStatus (int dd)
int	At45dbWaitReady (int dd, uint32_t tmo, int poll)
	Wait until flash memory cycle finished.
int	At45dbInit (unsigned int spibas, unsigned int spipcs)
	Initialize dataflash at specified interface and chip select.
int	At45dbPageErase (int dd, uint32_t pgn)
	Erase sector at the specified offset.
int	At45dbChipErase (void)
	Erase entire flash memory chip.
int	At45dbPageRead (int dd, uint32_t pgn, void *data, unsigned int len)
	Read data from flash memory.
int	At45dbPageWrite (int dd, uint32_t pgn, CONST void *data, unsigned int len)
	Write data into flash memory.
uint32_t	At45dbPages (int dd)
unsigned int	At45dbPageSize (int dd)
uint32_t	At45dbParamPage (void)
int	At45dbParamSize (void)
	Get size of configuration area.
int	At45dbParamRead (unsigned int pos, void *data, unsigned int len)
	Load configuration parameters from flash memory.
int	At45dbParamWrite (unsigned int pos, CONST void *data, unsigned int len)
	Store configuration parameters in flash memory.
Variables
AT45_DEVTAB	at45_devt []
	Table of known Dataflash types.
AT45 DataFlash Commands
#define	DFCMD_CONT_READ_LF 0x03
	Continuos read (low frequency).
#define	DFCMD_CONT_READ_HF 0x0B
	Continuos read (high frequency).
#define	DFCMD_BLOCK_ERASE 0x50
	Block erase.
#define	DFCMD_SECTOR_ERASE 0x7C
	Sector erase.
#define	DFCMD_PAGE_ERASE 0x81
	Page erase.
#define	DFCMD_BUF1_PROG 0x82
	Main memory page program through buffer 1.
#define	DFCMD_BUF1_FLASH 0x83
	Buffer 1 flash with page erase.
#define	DFCMD_BUF1_WRITE 0x84
	Buffer 1 write.
#define	DFCMD_BUF2_PROG 0x85
	Main memory page program through buffer 2.
#define	DFCMD_BUF2_FLASH 0x86
	Buffer 2 flash with page erase.
#define	DFCMD_BUF2_WRITE 0x87
	Buffer 2 write.
#define	DFCMD_BUF1_FLASH_NE 0x88
	Buffer 1 flash without page erase.
#define	DFCMD_BUF2_FLASH_NE 0x89
	Buffer 2 flash without page erase.
#define	DFCMD_CHIP_ERASE 0xC7
	Chip erase.
#define	DFCMD_BUF1_READ_LF 0xD1
	Buffer 1 read (low frequency).
#define	DFCMD_READ_PAGE 0xD2
	Read main memory page.
#define	DFCMD_BUF2_READ_LF 0xD3
	Buffer 2 read (low frequency).
#define	DFCMD_BUF1_READ 0xD4
	Buffer 1 read.
#define	DFCMD_BUF2_READ 0xD6
	Buffer 2 read.
#define	DFCMD_READ_STATUS 0xD7
	Read status register.
#define	DFCMD_CONT_READ 0xE8
	Continuos read (legacy).

Detailed Description

Routines for Atmel AT45 serial dataflash memory chips.

 *
 * $Log$
 * Revision 1.91 2010/12/15 15:20:42  ve2yag
 * Added MCU_AT91SAM7S family.
 *
 * Revision 1.9  2009/02/06 15:53:42  haraldkipp
 * Corrected a bug with non-negated chip selects.
 *
 * Revision 1.8  2009/01/17 11:26:46  haraldkipp
 * Getting rid of two remaining BSD types in favor of stdint.
 * Replaced 'u_int' by 'unsinged int' and 'uptr_t' by 'uintptr_t'.
 *
 * Revision 1.7  2008/12/15 19:18:49  haraldkipp
 * Enable DataFlash support for EIR board.
 *
 * Revision 1.6  2008/08/11 06:59:41  haraldkipp
 * BSD types replaced by stdint types (feature request #1282721).
 *
 * Revision 1.5  2008/08/06 12:51:09  haraldkipp
 * Added support for Ethernut 5 (AT91SAM9XE reference design).
 *
 * Revision 1.4  2008/02/15 17:10:43  haraldkipp
 * At45dbPageErase selected the wrong bank. Fixed. Parameter pgn (page number)
 * of At45dbPageWrite() changed from unsigned int to unsigned long.
 * New routines At45dbPages() and At45dbPageSize() allow to determine the
 * chip's layout.
 *
 * Revision 1.3  2007/08/17 10:45:21  haraldkipp
 * Enhanced documentation.
 *
 * Revision 1.2  2006/10/08 16:48:09  haraldkipp
 * Documentation fixed
 *
 * Revision 1.1  2006/09/29 12:41:55  haraldkipp
 * Added support for AT45 serial DataFlash memory chips. Currently limited
 * to AT91 builds.
 *
 *
 *

Definition in file at45db.c.

Define Documentation

#define MAX_AT45_DEVICES 1

Definition at line 93 of file at45db.c.

Referenced by At45dbInit().

#define MAX_AT45_CMDLEN 8

Definition at line 97 of file at45db.c.

Referenced by At45dbSendCmd().

#define AT45_CONF_DFSPI SPI0_BASE

Definition at line 101 of file at45db.c.

Referenced by At45dbParamSize(), and ShowHardwareConfiguration().

#define AT45_CONF_DFPCS 1

Definition at line 105 of file at45db.c.

Referenced by At45dbParamSize(), and ShowHardwareConfiguration().

#define AT45_ERASE_WAIT 3000

Definition at line 109 of file at45db.c.

#define AT45_CHIP_ERASE_WAIT 50000

Definition at line 113 of file at45db.c.

#define AT45_WRITE_POLLS 1000

Definition at line 117 of file at45db.c.

Referenced by At45dbPageWrite().

#define DFCMD_CONT_READ_LF 0x03

Continuos read (low frequency).

Reads a continous stream in low speed mode. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 130 of file at45db.c.

#define DFCMD_CONT_READ_HF 0x0B

Continuos read (high frequency).

Reads a continous stream in high speed mode. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 137 of file at45db.c.

#define DFCMD_BLOCK_ERASE 0x50

Block erase.

Definition at line 140 of file at45db.c.

#define DFCMD_SECTOR_ERASE 0x7C

Sector erase.

Definition at line 143 of file at45db.c.

#define DFCMD_PAGE_ERASE 0x81

Page erase.

Definition at line 146 of file at45db.c.

Referenced by At45dbPageErase().

#define DFCMD_BUF1_PROG 0x82

Main memory page program through buffer 1.

Definition at line 149 of file at45db.c.

#define DFCMD_BUF1_FLASH 0x83

Buffer 1 flash with page erase.

Definition at line 152 of file at45db.c.

Referenced by At45dbPageWrite().

#define DFCMD_BUF1_WRITE 0x84

Buffer 1 write.

Definition at line 155 of file at45db.c.

Referenced by At45dbPageWrite().

#define DFCMD_BUF2_PROG 0x85

Main memory page program through buffer 2.

Definition at line 158 of file at45db.c.

#define DFCMD_BUF2_FLASH 0x86

Buffer 2 flash with page erase.

Definition at line 161 of file at45db.c.

#define DFCMD_BUF2_WRITE 0x87

Buffer 2 write.

Definition at line 164 of file at45db.c.

#define DFCMD_BUF1_FLASH_NE 0x88

Buffer 1 flash without page erase.

Definition at line 167 of file at45db.c.

#define DFCMD_BUF2_FLASH_NE 0x89

Buffer 2 flash without page erase.

Definition at line 170 of file at45db.c.

#define DFCMD_CHIP_ERASE 0xC7

Chip erase.

Definition at line 173 of file at45db.c.

#define DFCMD_BUF1_READ_LF 0xD1

Buffer 1 read (low frequency).

Definition at line 176 of file at45db.c.

#define DFCMD_READ_PAGE 0xD2

Read main memory page.

Automatically wraps to the first byte of the same page after the last byte had been read. The data buffers are left unchanged.

Definition at line 182 of file at45db.c.

#define DFCMD_BUF2_READ_LF 0xD3

Buffer 2 read (low frequency).

Definition at line 185 of file at45db.c.

#define DFCMD_BUF1_READ 0xD4

Buffer 1 read.

Definition at line 188 of file at45db.c.

#define DFCMD_BUF2_READ 0xD6

Buffer 2 read.

Definition at line 191 of file at45db.c.

#define DFCMD_READ_STATUS 0xD7

Read status register.

Definition at line 194 of file at45db.c.

Referenced by At45dbGetStatus().

#define DFCMD_CONT_READ 0xE8

Continuos read (legacy).

Reads a continous stream. Automatically switches to the the page and wraps to the first page after the last has been read. Note, that the data buffers are not used for this operation.

Definition at line 201 of file at45db.c.

Referenced by At45dbPageRead().

#define AT45DB_AT91

Definition at line 204 of file at45db.c.

Typedef Documentation

typedef struct _AT45_DEVTAB AT45_DEVTAB

Known device type entry.

typedef struct _AT45DB_DCB AT45DB_DCB

Active device entry.

Function Documentation

int At45dbSendCmd	(	int	dd,
		uint8_t	op,
		uint32_t	parm,
		int	len,
		CONST void *	tdata,
		void *	rdata,
		int	datalen
	)

Send DataFlash command.

Parameters:

dd	Device descriptor.
op	Command operation code.
parm	Command parameter.
len	Command length.
tdata	Transmit data.
rdata	Receive data buffer.
datalen	Data length.

Definition at line 304 of file at45db.c.

References At91SpiTransfer2(), _AT45DB_DCB::dcb_cmdbuf, MAX_AT45_CMDLEN, and memset().

Referenced by At45dbPageErase(), At45dbPageRead(), and At45dbPageWrite().

Here is the call graph for this function:

uint8_t At45dbGetStatus ( int dd )

Definition at line 321 of file at45db.c.

References At91SpiTransfer2(), and DFCMD_READ_STATUS.

Referenced by At45dbInit(), and At45dbWaitReady().

Here is the call graph for this function:

int At45dbWaitReady	(	int	dd,
		uint32_t	tmo,
		int	poll
	)

Wait until flash memory cycle finished.

Returns:: 0 on success or -1 in case of an error.

Definition at line 336 of file at45db.c.

References At45dbGetStatus(), and NutSleep().

Referenced by At45dbPageWrite().

Here is the call graph for this function:

int At45dbInit	(	unsigned int	spibas,
		unsigned int	spipcs
	)

Initialize dataflash at specified interface and chip select.

Parameters:

spibas	Interface base address. For ARM MCUs this may be the I/O base address of the hardware SPI.
spipcs	Device chip select.

Returns:: Device descriptor or -1 in case of an error.

Definition at line 360 of file at45db.c.

References _BV, At45dbGetStatus(), At91SpiInit(), At91SpiInitChipSelects(), At91SpiReset(), At91SpiSetModeFlags(), At91SpiSetRate(), _AT45DB_DCB::dcb_devt, _AT45DB_DCB::dcb_spibas, _AT45DB_DCB::dcb_spipcs, _AT45_DEVTAB::devt_pages, MAX_AT45_DEVICES, SPIMF_CAPRISE, SPIMF_MASTER, and SPIMF_SCKIAHI.

Referenced by At45dbParamSize().

Here is the call graph for this function:

int At45dbPageErase	(	int	dd,
		uint32_t	pgn
	)

Erase sector at the specified offset.

Definition at line 402 of file at45db.c.

References At45dbSendCmd(), _AT45DB_DCB::dcb_devt, _AT45_DEVTAB::devt_offs, and DFCMD_PAGE_ERASE.

Here is the call graph for this function:

int At45dbChipErase ( void )

Erase entire flash memory chip.

Definition at line 411 of file at45db.c.

int At45dbPageRead	(	int	dd,
		uint32_t	pgn,
		void *	data,
		unsigned int	len
	)

Read data from flash memory.

Parameters:

dd	Device descriptor.
pgn	Page number to read, starting at 0.
data	Points to a buffer that receives the data.
len	Number of bytes to read.

Returns:: 0 on success or -1 in case of an error.

Definition at line 426 of file at45db.c.

References At45dbSendCmd(), _AT45DB_DCB::dcb_devt, _AT45_DEVTAB::devt_offs, and DFCMD_CONT_READ.

Referenced by At45dbParamRead(), and At45dbParamWrite().

Here is the call graph for this function:

int At45dbPageWrite	(	int	dd,
		uint32_t	pgn,
		CONST void *	data,
		unsigned int	len
	)

Write data into flash memory.

The related sector must have been erased before calling this function.

Parameters:

dd	Device descriptor.
pgn	Start location within the chip, starting at 0.
data	Points to a buffer that contains the bytes to be written.
len	Number of bytes to write.

Returns:: 0 on success or -1 in case of an error.

Definition at line 444 of file at45db.c.

References AT45_WRITE_POLLS, At45dbSendCmd(), At45dbWaitReady(), _AT45DB_DCB::dcb_devt, _AT45_DEVTAB::devt_offs, DFCMD_BUF1_FLASH, DFCMD_BUF1_WRITE, free(), and malloc().

Referenced by At45dbParamWrite().

Here is the call graph for this function:

uint32_t At45dbPages ( int dd )

Definition at line 463 of file at45db.c.

References _AT45DB_DCB::dcb_devt, and _AT45_DEVTAB::devt_pages.

unsigned int At45dbPageSize ( int dd )

Definition at line 468 of file at45db.c.

References _AT45DB_DCB::dcb_devt, and _AT45_DEVTAB::devt_pagsiz.

Referenced by ShowHardwareConfiguration().

uint32_t At45dbParamPage ( void )

Definition at line 473 of file at45db.c.

References _AT45DB_DCB::dcb_devt, and _AT45_DEVTAB::devt_pages.

Referenced by At45dbParamRead(), and At45dbParamWrite().

int At45dbParamSize ( void )

Get size of configuration area.

A part of the DataFlash may be used to store configuration parameters, like the network interface MAC address, the local hostname etc. The size of this area may be configured by defining AT45_CONF_SIZE. Otherwise one full page is used.

Returns:: The number of bytes available for configuration data. In case of an error, -1 is returned.

Definition at line 493 of file at45db.c.

References AT45_CONF_DFPCS, AT45_CONF_DFSPI, At45dbInit(), _AT45DB_DCB::dcb_devt, and _AT45_DEVTAB::devt_pagsiz.

Referenced by At45dbParamRead(), and At45dbParamWrite().

Here is the call graph for this function:

int At45dbParamRead	(	unsigned int	pos,
		void *	data,
		unsigned int	len
	)

Load configuration parameters from flash memory.

Parameters:

pos	Start location within configuration sector.
data	Points to a buffer that receives the contents.
len	Number of bytes to read.

Returns:: Always 0.

Definition at line 517 of file at45db.c.

References At45dbPageRead(), At45dbParamPage(), At45dbParamSize(), free(), malloc(), and memcpy().

Referenced by NutNvMemLoad().

Here is the call graph for this function:

int At45dbParamWrite	(	unsigned int	pos,
		CONST void *	data,
		unsigned int	len
	)

Store configuration parameters in flash memory.

Parameters:

pos	Start location within configuration sector.
data	Points to a buffer that contains the bytes to store.
len	Number of bytes to store.

Returns:: 0 on success or -1 in case of an error.

Definition at line 543 of file at45db.c.

References At45dbPageRead(), At45dbPageWrite(), At45dbParamPage(), At45dbParamSize(), free(), malloc(), memcmp(), and memcpy().

Referenced by NutNvMemSave().

Here is the call graph for this function:

Variable Documentation

AT45_DEVTAB at45_devt[]

Initial value:

 {
    {512, 264, 9, 0x3C, 0x0C},
    {1025, 264, 9, 0x3C, 0x14},
    {2048, 264, 9, 0x3C, 0x1C},
    {4096, 264, 9, 0x3C, 0x24},
    {4096, 528, 10, 0x3C, 0x2C},
    {8192, 528, 10, 0x3C, 0x34},
    {8192, 1056, 11, 0x38, 0x38},
    {0, 0, 0, 0, 0}
}

Table of known Dataflash types.

Definition at line 271 of file at45db.c.

Data Structures

Defines

Typedefs

Functions

Variables

AT45 DataFlash Commands

Detailed Description

Define Documentation

Typedef Documentation

Function Documentation

Variable Documentation
