ace.h File Reference

ACE I/O function prototypes. More...

#include <sys/device.h>
Include dependency graph for ace.h:
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Defines

#define ACE_SETSPEED   0x0101
 ACE _ioctl() command code to set the line speed.
#define ACE_GETSPEED   0x0102
 ACE _ioctl() command code to query the line speed.
#define ACE_SETDATABITS   0x0103
 ACE _ioctl() command code to set the number of data bits.
#define ACE_GETDATABITS   0x0104
 ACE _ioctl() command code to query the number of data bits.
#define ACE_SETPARITY   0x0105
 ACE _ioctl() command code to set the parity mode.
#define ACE_GETPARITY   0x0106
 ACE _ioctl() command code to query the parity mode.
#define ACE_SETSTOPBITS   0x0107
 ACE _ioctl() command code to set the number of stop bits.
#define ACE_GETSTOPBITS   0x0108
 ACE _ioctl() command code to query the number of stop bits.
#define ACE_SETSTATUS   0x0109
 ACE _ioctl() command code to set the status.
#define ACE_GETSTATUS   0x010a
 ACE _ioctl() command code to query the status.
#define ACE_SETREADTIMEOUT   0x010b
 ACE _ioctl() command code to set the read timeout.
#define ACE_GETREADTIMEOUT   0x010c
 ACE _ioctl() command code to query the read timeout.
#define ACE_SETWRITETIMEOUT   0x010d
 ACE _ioctl() command code to set the write timeout.
#define ACE_GETWRITETIMEOUT   0x010e
 ACE _ioctl() command code to query the write timeout.
#define ACE_SETLOCALECHO   0x010f
 ACE _ioctl() command code to set the local echo mode.
#define ACE_GETLOCALECHO   0x0110
 ACE _ioctl() command code to query the local echo mode.
#define ACE_SETFLOWCONTROL   0x0111
 ACE _ioctl() command code to set the flow control mode.
#define ACE_GETFLOWCONTROL   0x0112
 ACE _ioctl() command code to query the flow control mode.
#define ACE_SETCOOKEDMODE   0x0113
 ACE _ioctl() command code to set the cooking mode.
#define ACE_GETCOOKEDMODE   0x0114
 ACE _ioctl() command code to query the cooking mode.
#define ACE_SETBUFFERMODE   0x0115
 ACE _ioctl() command code to set the buffering mode.
#define ACE_GETBUFFERMODE   0x0116
 ACE _ioctl() command code to query the buffering mode.
#define ACE_SETTXBUFSIZ   0x011b
 ACE _ioctl() command code to set the transmit buffer size.
#define ACE_GETTXBUFSIZ   0x011c
 ACE _ioctl() command code to query the transmit buffer size.
#define ACE_SETRXBUFSIZ   0x011d
 ACE _ioctl() command code to set the receive buffer size.
#define ACE_GETRXBUFSIZ   0x011e
 ACE _ioctl() command code to query the receive buffer size.
#define ACE_SETTXBUFLWMARK   0x0120
 ACE _ioctl() command code to set the transmit buffer low watermark.
#define ACE_GETTXBUFLWMARK   0x0121
 ACE _ioctl() command code to query the transmit buffer low watermark.
#define ACE_SETTXBUFHWMARK   0x0122
 ACE _ioctl() command code to set the transmit buffer high watermark.
#define ACE_GETTXBUFHWMARK   0x0123
 ACE _ioctl() command code to query the transmit buffer high watermark.
#define ACE_SETRXBUFLWMARK   0x0124
 ACE _ioctl() command code to set the receive buffer low watermark.
#define ACE_GETRXBUFLWMARK   0x0125
 ACE _ioctl() command code to query the receive buffer low watermark.
#define ACE_SETRXBUFHWMARK   0x0126
 ACE _ioctl() command code to set the receive buffer high watermark.
#define ACE_GETRXBUFHWMARK   0x0127
 ACE _ioctl() command code to query the receive buffer high watermark.
#define ACE_SETBLOCKREAD   0x0128
 ACE _ioctl() command code to set the block read mode.
#define ACE_GETBLOCKREAD   0x0129
 ACE _ioctl() command code to query the receive buffer high watermark.
#define ACE_SETFIFO   0x012a
 ACE _ioctl() command code to set the fifo mode and receive fifo trigger level.
#define ACE_GETFIFO   0x012b
 ACE _ioctl() command code to query the fifo mode and receive fifo trigger level.
#define ACE_FRAMINGERROR   0x00000001UL
 Framing error.
#define ACE_OVERRUNERROR   0x00000002UL
 Overrun error.
#define ACE_PARITYERROR   0x00000004UL
 Parity error.
#define ACE_ERRORS   (ACE_FRAMINGERROR | ACE_OVERRUNERROR | ACE_PARITYERROR)
 ACE errors.
#define ACE_RXBUFFEREMPTY   0x00000040UL
 Receiver buffer empty.
#define ACE_TXBUFFEREMPTY   0x00000080UL
 Transmitter buffer empty.
#define ACE_RTSENABLED   0x00000100UL
 RTS handshake output enabled.
#define ACE_RTSDISABLED   0x00000200UL
 RTS handshake output disabled.
#define ACE_CTSENABLED   0x00000400UL
 CTS handshake input enabled.
#define ACE_CTSDISABLED   0x00000800UL
 CTS handshake input disabled.
#define ACE_DTRENABLED   0x00001000UL
 DTR handshake output enabled.
#define ACE_DTRDISABLED   0x00002000UL
 DTR handshake output disabled.
#define ACE_RXENABLED   0x00010000UL
 Receiver enabled.
#define ACE_RXDISABLED   0x00020000UL
 Receiver enabled.
#define ACE_TXENABLED   0x00040000UL
 Transmitter enabled.
#define ACE_TXDISABLED   0x00080000UL
 Transmitter enabled.
#define ACE_HS_RTSCTS   0x0003
 RTS / CTS hardware handshake.
#define ACE_HS_MODEM   0x001F
 Full modem hardware handshake.
#define ACE_HS_SOFT   0x0020
 XON / XOFF software handshake.

Functions

int AceInit (NUTDEVICE *dev)
 Initialize on chip ACE device.
int AceIOCtl (NUTDEVICE *dev, int req, void *conf)
 Perform ACE control functions.
int AceInput (NUTDEVICE *dev)
 Wait for input.
int AceOutput (NUTDEVICE *dev)
 Initiate output.
int AceFlush (NUTDEVICE *dev)
 Wait for output buffer empty.
int AceGetRaw (uint8_t *cp)
int AcePutRaw (uint8_t ch)
int AceRead (NUTFILE *fp, void *buffer, int size)
 Read from device.
int AceWrite (NUTFILE *fp, CONST void *buffer, int len)
int AceWrite_P (NUTFILE *fp, PGM_P buffer, int len)
NUTFILEAceOpen (NUTDEVICE *dev, CONST char *name, int mode, int acc)
 Open a device or file.
long AceSize (NUTFILE *fp)
 Request file size.
int AceClose (NUTFILE *fp)
 Close a device or file.

Detailed Description

ACE I/O function prototypes.

Definition in file ace.h.


Function Documentation

int AceInit ( NUTDEVICE dev)

Initialize on chip ACE device.

Prepares the device for subsequent reading or writing. Enables ACE transmitter and receiver interrupts.

Parameters:
devIdentifies the device to initialize.
Returns:
0 on success, -1 otherwise.

Definition at line 743 of file tlc16c550.c.

References ACE_MF_NOBUFFER, ACE_SETDATABITS, ACE_SETFLOWCONTROL, ACE_SETPARITY, ACE_SETSPEED, ACE_SETSTOPBITS, AceFlush(), AceInput(), AceIOCtl(), AceOutput(), _ACEDCB::dcb_modeflags, _ACEDCB::dcb_rfifo, _ACEDCB::dcb_wfifo, _NUTDEVICE::dev_base, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _NUTDEVICE::dev_irq, _ACEDCB::dev_next, _NUTDEVICE::dev_type, _IFSTREAM::if_flush, _IFSTREAM::if_input, _IFSTREAM::if_output, IFTYP_STREAM, memset(), tagIRQDEFS::nMask, NutRegisterIrqHandler(), tagIRQDEFS::pnIrqMskPort, tagIRQDEFS::pvIrq, sbi, and sig_OUTPUT_COMPARE3A.

Here is the call graph for this function:

int AceIOCtl ( NUTDEVICE dev,
int  req,
void *  conf
)

Perform ACE control functions.

Parameters:
devIdentifies the device that receives the device-control function.
reqRequested control function. May be set to one of the following constants:
  • ACE_SETSPEED, conf points to an uint32_t value containing the baudrate.
  • ACE_GETSPEED, conf points to an uint32_t value receiving the current baudrate.
  • ACE_SETDATABITS, conf points to an uint32_t value containing the number of data bits, 5, 6, 7 or 8.
  • ACE_GETDATABITS, conf points to an uint32_t value receiving the number of data bits, 5, 6, 7 or 8.
  • ACE_SETPARITY, conf points to an uint32_t value containing the parity, 0 (no), 1 (odd) or 2 (even).
  • ACE_GETPARITY, conf points to an uint32_t value receiving the parity, 0 (no), 1 (odd) or 2 (even).
  • ACE_SETSTOPBITS, conf points to an uint32_t value containing the number of stop bits 1 or 2.
  • ACE_GETSTOPBITS, conf points to an uint32_t value receiving the number of stop bits 1 or 2.
  • ACE_SETSTATUS
  • ACE_GETSTATUS
  • ACE_SETREADTIMEOUT, conf points to an uint32_t value containing the read timeout.
  • ACE_GETREADTIMEOUT, conf points to an uint32_t value receiving the read timeout.
  • ACE_SETWRITETIMEOUT, conf points to an uint32_t value containing the write timeout.
  • ACE_GETWRITETIMEOUT, conf points to an uint32_t value receiving the write timeout.
  • ACE_SETLOCALECHO, conf points to an uint32_t value containing 0 (off) or 1 (on).
  • ACE_GETLOCALECHO, conf points to an uint32_t value receiving 0 (off) or 1 (on).
  • ACE_SETFLOWCONTROL, conf points to an uint32_t value containing combined ACE_FCR_ values.
  • ACE_GETFLOWCONTROL, conf points to an uint32_t value containing receiving ACE_FCR_ values.
  • ACE_SETCOOKEDMODE, conf points to an uint32_t value containing 0 (off) or 1 (on).
  • ACE_GETCOOKEDMODE, conf points to an uint32_t value receiving 0 (off) or 1 (on).
confPoints to a buffer that contains any data required for the given control function or receives data from that function.
Returns:
0 on success, -1 otherwise.
Warning:
Timeout values are given in milliseconds and are limited to the granularity of the system timer. To disable timeout, set the parameter to NUT_WAIT_INFINITE.

Definition at line 484 of file tlc16c550.c.

References ACE_CLOCK, ACE_DLL_OFS, ACE_DLM_OFS, ACE_FCR_OFS, ACE_FIFO_SIZE, ACE_GETCOOKEDMODE, ACE_GETDATABITS, ACE_GETFIFO, ACE_GETFLOWCONTROL, ACE_GETLOCALECHO, ACE_GETPARITY, ACE_GETREADTIMEOUT, ACE_GETSPEED, ACE_GETSTATUS, ACE_GETSTOPBITS, ACE_GETWRITETIMEOUT, ACE_LCR_OFS, ACE_MF_COOKEDMODE, ACE_MF_HALFDUPLEX, ACE_MF_LOCALECHO, ACE_SETCOOKEDMODE, ACE_SETDATABITS, ACE_SETFIFO, ACE_SETFLOWCONTROL, ACE_SETLOCALECHO, ACE_SETPARITY, ACE_SETREADTIMEOUT, ACE_SETSPEED, ACE_SETSTATUS, ACE_SETSTOPBITS, ACE_SETWRITETIMEOUT, _ACEDCB::dcb_modeflags, _ACEDCB::dcb_rfifo, _ACEDCB::dcb_rtimeout, _ACEDCB::dcb_tx_rdy, _ACEDCB::dcb_wfifo, _ACEDCB::dcb_wtimeout, _NUTDEVICE::dev_base, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, FCR_ENABLE, FCR_LEVEL_1, FCR_LEVEL_14, FCR_LEVEL_4, FCR_LEVEL_8, FCR_PURGE_I, FCR_PURGE_O, _IFSTREAM::if_tx_act, _IFSTREAM::if_tx_idx, _IFSTREAM::if_wr_idx, LCR_ENB_MSK, LCR_PEN_MSK, LCR_PRE_MSK, LCR_PRS_MSK, LCR_STB_MSK, LCR_WS0_MSK, LCR_WS1_MSK, and NutEventPostAsync().

Referenced by AceInit().

Here is the call graph for this function:

int AceInput ( NUTDEVICE dev)

Wait for input.

This function checks the input buffer for any data. If the buffer is empty, the calling thread will be blocked until at least one new character is received or a timeout occurs.

Parameters:
devIndicates the ACE device.
Returns:
0 on success, -1 on timeout.

Definition at line 305 of file tlc16c550.c.

References _ACEDCB::dcb_rtimeout, _ACEDCB::dcb_rx_rdy, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _IFSTREAM::if_rd_idx, _IFSTREAM::if_rx_idx, and NutEventWaitNext().

Referenced by AceInit(), and AceRead().

Here is the call graph for this function:

int AceOutput ( NUTDEVICE dev)

Initiate output.

This function checks the output buffer for any data. If the buffer contains at least one character, the transmitter is started, if not already running. The function returns immediately, without waiting for the character being completely transmitted. Any remaining characters in the output buffer are transmitted in the background.

Parameters:
devIndicates the ACE device.
Returns:
0 on success, -1 otherwise.

Definition at line 331 of file tlc16c550.c.

References ACE_MF_HALFDUPLEX, ACE_THR_OFS, _ACEDCB::dcb_modeflags, _ACEDCB::dcb_wfifo, _NUTDEVICE::dev_base, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _IFSTREAM::if_tx_act, _IFSTREAM::if_tx_buf, _IFSTREAM::if_tx_idx, and _IFSTREAM::if_wr_idx.

Referenced by AceFlush(), and AceInit().

int AceFlush ( NUTDEVICE dev)

Wait for output buffer empty.

If the output buffer contains any data, the calling thread is suspended until all data has been transmitted.

Parameters:
devIndicates the ACE device.
Returns:
0 on success, -1 otherwise.

Definition at line 365 of file tlc16c550.c.

References AceOutput(), _ACEDCB::dcb_tx_rdy, _NUTDEVICE::dev_dcb, _NUTDEVICE::dev_icb, _IFSTREAM::if_tx_idx, _IFSTREAM::if_wr_idx, and NutEventWaitNext().

Referenced by AceInit(), and AcePut().

Here is the call graph for this function:

int AceGetRaw ( uint8_t cp)
int AcePutRaw ( uint8_t  ch)
int AceRead ( NUTFILE fp,
void *  buffer,
int  size
)
int AceWrite ( NUTFILE fp,
CONST void *  buffer,
int  len
)

Definition at line 967 of file tlc16c550.c.

References AcePut(), and _NUTFILE::nf_dev.

Here is the call graph for this function:

int AceWrite_P ( NUTFILE fp,
PGM_P  buffer,
int  len
)

Definition at line 972 of file tlc16c550.c.

References AcePut(), CONST, and _NUTFILE::nf_dev.

Here is the call graph for this function:

NUTFILE* AceOpen ( NUTDEVICE dev,
CONST char *  name,
int  mode,
int  acc
)
long AceSize ( NUTFILE fp)

Request file size.

Definition at line 1015 of file tlc16c550.c.

References _NUTDEVICE::dev_icb, _IFSTREAM::if_rd_idx, _IFSTREAM::if_rx_idx, and _NUTFILE::nf_dev.

int AceClose ( NUTFILE fp)

Close a device or file.

Definition at line 1005 of file tlc16c550.c.

References NutHeapFree.
